Start-up
UPC Open Carrier Proprietary and Confidential CARRIER CORPORATION ©2017
Installation and Integration Guide All rights reserved
16
6 Do one of the following:
If the control program is...
In the
Control Program drop-down list
Select the control program.
Not in the Control Program drop-down list
a.
Click Add New.
b. Browse to select the control program.
c. Click Open.
d. Click Continue.
e. Click Close.
7 To upload a graphic, click Add New under Views and browse to your .view file.
8 Click Continue. When message appears File added successfully, click Close.
9 Click Close
again.
10 Right-click on the programmable controller in the controller list and select Check Status from the list. The
status of the controller should say File Mismatch.
11 Click the Download All Content button.
12 Assign channel numbers to the physical points by selecting the controller in the navigation tree and going to
Properties page > I/O Points tab.
○ Enter your channel numbers under Num, using your wire list.
○ Enter your expander address under
Exp, if applicable.
○ Select the appropriate value under Sensor/Actuator Type, if applicable.
13
Configure the controller on the Properties page >
Control Program
tab.
14 Check out and commission the equipment.
Configure the UPC Open's properties
To start up the UPC Open, set the following properties:
Navigation:
i-Vu® / Field Assistant:
BACview®:
Properties > Control Program > Status
CCN
Point Name/Description
Default/Range
Element Comm Stat - The UPC Open's current status of communication to the CCN
equipment. Click the Element Comm Stat microblock link to change the CCN
equipment target address - bus and element number.
NOTE If more than one UPC Open is connected to a CCN bus for a Multiple Chiller
Application, you must change the CCN controller's address in this object's
Summary
tab.
D:
R:
0, 1
Bus: 0.1 - 239
Element: 1 - 239
