APPENDIX A — LOCAL DISPLAY TABLES
MODE — RUN STATUS
ITEM EXPANSION RANGE UNITS CCN POINT WRITE STATUS PAGE NO.
VIEW AUTO VIEW OF RUN STATUS
HVAC ascii string spelling out the hvac modes string 102
OCC Occupied ? YES/NO OCCUPIED forcible 102
MAT Mixed Air Temperature -40 to 240 dF MAT 102
EDT Evaporator Discharge Tmp -40 to 240 dF EDT 112
LAT Leaving Air Temperature -40 to 240 dF LAT 80,112
EC.C.P Economizer Control Point 0 to 180 dF ECONCPNT 112
EC1.P
Econ 1 Out Act.Curr.Pos. 0 to 100 % ECONOPOS 112
EC2.P Econ 2 Ret Act.Curr.Pos. 0 to 100 % ECON2POS 112
EC3.P Econ 3 Out Act.Curr.Pos. 0 to 100 % ECON3POS 112
CL.C.P Cooling Control Point -20 to 140 dF COOLCPNT 50,51,112
C.CAP Current Running Capacity 0 to 100 % CAPTOTAL 112
CL.ST Requested Cool Stage 0 to 20 CL_STAGE 112
HT.C.P Heating Control Point -20 to 140 dF HEATCPNT 65,112,124
HT.ST Requested Heat Stage 0 to 20 HT_STAGE 65-67,112
H.MAX Maximum Heat Stages 0 to 20 HTMAXSTG 66,112
ECON ECONOMIZER RUN STATUS
EC1.P Econ 1 Out Act.Curr.Pos. 0 to 100 % ECONOPOS 61,80,113
EC2.P Econ 2 Ret Act.Curr.Pos. 0 to 100 % ECON2POS 61,80,113
EC3.P Econ 3 Out Act.Curr.Pos. 0 to 100 % ECON3POS 61,80,113
ECN.C Econ 1 Out Act.Cmd.Pos. 0 to 100 % ECONOCMD forcible 80,113
ACTV Economizer Active ? YES/NO ECACTIVE 61,80,113
DISA
ECON DISABLING CONDITIONS
DISAUNV.1 Econ1 Out Act Unvailable? YES/NO ECONUNAV 80,113
DISAUNV.2 Econ2 Ret Act Unvailable? YES/NO ECN2UNAV 80,113
DISAUNV.3 Econ3 Out Act Unvailable? YES/NO ECN3UNAV 80,113
DISAENTH Enth. Switch Read High ? YES/NO ENTH 80,113
DISADBC DBC - OAT Lockout? YES/NO DBC_STAT 80,113
DISADEW DEW - OA Dewpt.Lockout? YES/NO DEW_STAT 80,113
DISADDBC DDBD- OAT > RAT Lockout? YES/NO DDBCSTAT 74,80,113
DISAOAEC OAEC- OA Enth Lockout? YES/NO OAECSTAT 80,113
DISADEC DEC - Diff.Enth.Lockout? YES/NO DEC_STAT 80,113
DISAEDT EDT Sensor Bad? YES/NO EDT_STAT 80,113
DISAOAT OAT Sensor Bad ? YES/NO OAT_STAT 80,113
DISAFORC Economizer Forced ? YES/NO ECONFORC 80,113
DISASFON Supply Fan Not On 30s ? YES/NO SFONSTAT 80,113
DISACLOF Cool Mode Not In Effect? YES/NO COOL_OFF 80,113
DISAOAQL OAQ Lockout in Effect ? YES/NO OAQLOCKD 80,113
DISAHELD Econ Recovery Hold Off? YES/NO ECONHELD 80,113
DISADH.DS Dehumid. Disabled Econ.? YES/NO DHDISABL 80,113
O.AIR OUTSIDE AIR INFORMATION 80,113
O.AIROAT Outside Air Temperature -40 to 240 dF OAT forcible 80,113
O.AIROA.RH Outside Air Rel. Humidity 0 to 100 % OARH forcible 80,113
O.AIROA.E Outside Air Enthalpy -20 to 10000 OAE 80,113
O.AIROA.D.T OutsideAir Dewpoint Temp -40 to 240 dF OADEWTMP 80,113
COOL COOLING INFORMATION
C.CAP
Current Running Capacity 0 to 100 % CAPTOTAL 52,53,55,112,
113
CUR.S Current Cool Stage 0 to 20 COOL_STG 52,53,112,113
REQ.S Requested Cool Stage 0 to 20 CL_STAGE 52,53,112,113
MAX.S Maximum Cool Stages 0 to 20 CLMAXSTG 52,53,112,113
DEM.L
Active Demand Limit 0 to 100 % DEM_LIM forcible 52,53,55,112,
113
SUMZ
COOL CAP. STAGE CONTROL
SUMZSMZ Capacity Load Factor -400 to 400 SMZ 52,53,112,113
SUMZADD.R Next Stage EDT Decrease 0 to 30 ADDRISE 52,53,112,113
SUMZSUB.R Next Stage EDT Increase 0 to 30 SUBRISE 52,53,112,113
SUMZR.PCT Rise Per Percent Capacity 0 to 10 RISE_PCT 52,53,112,113
SUMZY.M I N Cap Deadband Subtracting -40 to 0 Y_MINUS 52,53,112,113
SUMZY.PL U Cap Deadband Adding 0 to 40 Y_PLUS 52,53,112,113
SUMZZ.MIN Cap Threshold Subtracting -99 to 0 Z_MINUS 52,53,113
SUMZZ.PLU Cap Threshold Adding 0 to 99 Z_PLUS 52,53,113
SUMZH.TMP High Temp Cap Override YES/NO HI_TEMP 52,53,113
SUMZL.TMP Low Temp Cap Override YES/NO LOW_TEMP 52,53,113,114
SUMZPULL Pull Down Cap Override YES/NO PULLDOWN 53,113,114
SUMZSLOW Slow Change Cap Override YES/NO SLO_CHNG 53,113,114
HMZR
HUMIDIMIZER
HMZRCAPC HumidiMizer Capacity 0 to 100 % HMZRCAPC 53
HMZRC.EXV Condenser EXV Position 0 to 100 % COND_EXV 53
HMZRB.EXV Bypass EXV Position 0 to 100 % BYP_EXV 53
HMZRRHV HumidiMizer 3-way Valve YES/NO HUM3WVAL 53
HMZRC.CPT Cooling Control Point -20 to 140 dF COOLCPNT 53
HMZREDT Evaporator Discharge Temp -40 to 240 dF EDT 53
HMZRH.CPT Heating Control Point -20 to 140 dF HEATCPNT 53
HMZRLAT Leaving Air Temperature -40 to 240 dF LAT 53
EXVS EXVS INFORMATION
A1.EX Circuit A EXV 1 Position 0 to 100 % XV1APOSP 53,113
A2.EX Circuit A EXV 2 Position 0 to 100 % XV2APOSP 53,113
B1.EX Circuit B EXV 1 Position 0 to 100 % XV1BPOSP 53,113
B2.EX Circuit B EXV 2 Position 0 to 100 % XV2BPOSP 53,113
SH.A1 Cir A EXV1 Superheat Tmp -100 to 200 ^F SH_A1 53,113
SH.A2 Cir A EXV2 Superheat Tmp -100 to 200 ^F SH_A2 53,113
SH.B1 Cir B EXV1 Superheat Tmp -100 to 200 ^F SH_B1 53,113
SH.B2 Cir B EXV2 Superheat Tmp -100 to 200 ^F SH_B2 53,113
CTRL
EXVS CONTROL INFORMATION
CTRLC.SHS
EXV Superheat Ctrl SP 5 to 40 ^F SH_SP_CT forcible 53,113,117,
124
CTRLC.FLS EXV SH Flooding Ctrl SP 0 to 10 ^F FL_SP_CT forcible 53,113
CTRLC.EXP EXV PID Ctrl Prop. Gain 0 to 5 EXV_PG_C forcible 53,113
CTRLC.EXT EXV Ctrl Integrat. Time 0.5 to 60 EXV_TI_C forcible 53,113
CTRLC.EXM Cir Strt EXV Mn Ctrl Pos 0 to 100 % EXCSMP_C forcible 53,113
