Carrier WeatherMaker 48TC Series - Cooling; Physical Data

13
Table 7 – PHYSICAL DATA (COOLING) 3 -- 6 TONS
48TC*A04 48TC*A05 48TC*A06 48TC*A07
Refrigeration System
#Circuits/#Comp./Type 1/1/Scroll 1/1/Scroll 1/1/Scroll 1/1/Scroll
Puronr refrig. (R--- 410A) (lbs--- oz) 5 --- 1 0 8 --- 8 10--- 11 1 4 --- 2
H u m i d i --- M i Z e r P u r o n r r e f r i g . c h a r g e A / B ( l b s --- o z ) 8 --- 1 1 14--- 13 1 6 --- 0 2 2 --- 5
Metering Device Acutrol Acutrol Acutrol Acutrol
High---press. Trip / Reset (psig) 630 / 505 630 / 505 630 / 505 630 / 505
Low--- press. Trip / Reset (psig) 54 / 117 54 / 117 54 / 117 54 / 117
Compressor Capacity Staging (%) 100% 100% 100% 100%
Evap. Coil
Material (Tube/Fin) Cu / Al Cu / Al Cu / Al Cu / Al
Coil type 3/8---in RTPF 3 / 8 --- i n R T P F 3 / 8 --- i n R T P F 3 / 8 --- i n R T P F
Rows / FPI 2 / 15 2/15 4/15 4/15
Tot al Fa ce Ar ea ( ft
2
)5.5 5.5 5.5 7.3
Condensate Drain Conn. Size 3/4--- in 3 / 4 --- i n 3 / 4 --- i n 3 / 4 --- i n
Evap. Fan and Motor
Standard Static
1phase
Motor Qty / Drive Type 1/Belt
1/Belt 1/Belt ---
Max BHP 1.2
1.2 1.2 ---
RPM Range 560--- 854 560--- 854 770--- 1175 ---
Motor Frame Size 48 48 48 ---
Fan Qty / Type 1/Centrifugal 1/Centrifugal 1/Centrifugal ---
Fan Diameter (in) 10 x 10 10 x 10 10 x 10 ---
Medium Static
1phase
Motor Qty / Drive Type 1/Belt 1/Belt 1/Belt ---
Max BHP 1.2 1.2 1.5 ---
RPM Range 770--- 1175 770--- 1175 1035--- 1466 ---
Motor Frame Size 48 48 56 ---
Fan Qty / Type 1/Centrifugal 1/Centrifugal 1/Centrifugal ---
Fan Diameter (in) 10 x 10 10 x 10 10 x 10 ---
Standard Static
3phase
Motor Qty / Drive Type 1/Belt 1/Belt 1/Belt 1/Belt
Max BHP 1.7 1.7 1.7 2.4
RPM Range 560--- 854 560--- 854 770--- 1175 1073--- 1457
Motor Frame Size 48 48 48 56
Fan Qty / Type 1/Centrifugal 1/Centrifugal 1/Centrifugal 1/Centrifugal
Fan Diameter (in) 10 x 10 10 x 10 10 x 10 10 x 10
Medium Static
3phase
Motor Qty / Drive Type 1/Belt 1/Belt 1/Belt 1/Belt
Max BHP 1.7 1.7 2.4 2.9*
RPM Range 770--- 1175 770--- 1175 1035--- 1466 1173--- 1518
Motor Frame Size 48 48 56 56
Fan Qty / Type 1/Centrifugal 1/Centrifugal 1/Centrifugal 1/Centrifugal
Fan Diameter (in) 10 x 10 10 x 10 10 x 10 10 x 10
High Static
3phase
Motor Qty / Drive Type 1/Belt 1/Belt 1/Belt 1/Belt
Max BHP 2.4 2.4 2.9 3.7
RPM Range 1035--- 1466 1035--- 1466 1303--- 1687 1474--- 1788
Motor Frame Size 56 56 56 56
Fan Qty / Type 1/Centrifugal 1/Centrifugal 1/Centrifugal 1/Centrifugal
Fan Diameter (in) 10 x 10 10 x 10 10 x 10 10 x 10
Cond. Coil
Material (Tube/Fin) Cu / Al Cu / Al Cu / Al Cu / Al
Coil type 3/8---in RTPF 3 / 8 --- i n R T P F 3 / 8 --- i n R T P F 3 / 8 --- i n R T P F
Rows / FPI 1 / 17 2/17 2/17 2/17
Tot al Fa ce Ar ea ( ft
2
) 14.6 16.5 16.5 21.3
H u m i d i --- M i Z e r C o i l
Material (Tube/Fin) Cu / Al Cu / Al Cu / Al Cu / Al
Rows..Fins/in. 1 / 17 2/17 2/17 2/17
Tot al Fa ce Ar ea ( ft
2
)3.9 3.9 3.9 5.2
Cond. fan / motor
Qty / Motor Drive Type 1/ Direct 1/ Direct 1/ Direct 1/ Direct
Motor HP / RPM 1/4 / 1100 1/4 / 1100 1/4 / 1100 1/4 / 1100
Fan diameter (in) 22 22 22 22
Filters
RA Filter # / Size (in) 2 / 16 x 25 x 2 2/16x25x2 2/16x25x2 4/16x16x2
OA inlet screen # / Size (in) 1/20x24x1 1/20x24x1 1/20x24x1 1/20x24x1
NOTE: Humidi---MiZer is not available with Novation condenser coil models, only Round Tube / Plate Fin (RTPF).
* 575V motor utilizes 3.7 BHP.
--- N o t a p p l i c a b l e
