General Information
6
1.5.3 Convenient for maintenance
The high/low pressure valves adopt the Stop Valves, which
have screwed thread nipple joint, can be connected to the
meter connector directly in air tight test. And also make it
more efficient and easy for installation.
Convenient electronic control check window. Can
directly observe the operation status from the
LED display, and directly press the FORCE
COOLING / CHECK button.
Self diagnosis function and four-digit Digital display, help
service engineer to find out the fault fast and easily.

Carrier X-POWER Series Specifications

General

Type	Inverter
Refrigerant	R410A
Operating Temperature Range (Heating)	-15°C to 24°C
Power Supply	220 - 240V, 50/60Hz
Operating Temperature Range (Cooling)	5°C to 46°C
