19
UPPER FOUR LOWER FOUR (“J curve settings)
OUTPUT
HI (ch1) LO-MID (ch2) SUB (ch3) HI (ch4) LO-MID (ch5) SUB (ch6)
Output Gain
-9 dB
0.0 dB
-9 dB (-15db)
0.0 dB
0.0 dB
Input Source
A
A
not used A
A
A
(Alt Source)
(C for Aux sub)
Polarity
OUT IN OUT IN IN
20kHz 1.5kHz 20kHz 1.5kHz 80Hz
LPF frequency
OUT
Butter 48
OUT
Butter 48
Linkwtz 24
LPF type
1.5 KHz
80 Hz
1.5 KHz
80 Hz
32 Hz
HPF frequency
Butter 48
Linkwtz 24
Butter 48
Linkwtz 24
Butter 18
HPF type
-3 0 -3 0 0
Limit Threshold
84 uS
0.0 mS
84 uS
0.0 mS
0.0 mS
Output Delay
-6 dB 9 dB -6 dB 9 dB (0db)
PEQ1 GAIN
2 KHz
400 Hz
2 KHz
400 Hz
PEQ1 FREQ
1
0.12
1
0.12
PEQ1 BW
12 dB 12 dB (-9dB)
PEQ2 GAIN
12 KHz 12 KHz (315 Hz)
PEQ2 FREQ
3 3 (0.3)
PEQ2 BW
0.12 0.12
Bi Amp 8 array modules straight hang
Lower four cabinets can be adjusted for “J” curve see settings.
8 enclosure Line Array
