1-GENERALINFORMATION
Steeringcylinders
Thesteeringcylindersareconnectedtotherearframe
andtheirpistonrodsareconnectedtothearticulation
joint.
PTIL14COM0084AA11
Fueltank
Theboxshapedhollowspaceattherearoftheframe
servesasthefueltank.Thefueltankisprovidedwith
afuellevelsensorwhichindicatesthediesellevelinthe
tank.Altercapisprovidedwithadustlterandavent
hole.Adrainplugisprovidedatthebottomofthefuel
tank.
PTIL14COM0085AA12
Hydraulicoiltank
Thehydraulicoiltankisprovidedwithahydraulicoillevel
sightgauge.
PTIL14COM0086AA13
Frontrollerframe
Thefrontrollerframesupportsthefrontrollerassembly
vibrationmotor,drumdrivemotor.Thisrollerframeis
connectedtotherearchassisbymeansofanarticulation
joint.
PTIL14COM0087AA14
1-13
