1-GENERALINFORMATION

Rearchassis

Therearchassissupportstherearaxleassembly,engine,

hydraulicoiltank,driversplatformetc.Thisisconnected

tothefrontrollerframebymeansofanarticulationjoint.

PTIL14COM0088AA15

Frontdrum

Thefrontdrumiscoupledtothevibrationmotorthrough

elasticsuspensionattheright-handsideandtothe

propulsionmotorthroughvibrationdampersatthe

left-handside.

PTIL14COM0089AA16

Tires

Thetiresusedonthemachinearetubelesstires.Thesize

ofthetiresis23.1/18-26/12PR.Cleanwaterislledinside

thesetiresupto75%ofthevolume.

NOTE:Donotusedirtywaterforllingthetires.

PTIL14COM0090AA17

Excitershaft(vibration)

Theexcitershaftissupportedontwobearingsandthevi-

brationmotoriscoupledtoitthroughcoupling.Twooat-

ingmassesareresponsibleforprovidingdualamplitude.

PTIL14COM0091AA18

1-14
