3-CONTROLSANDINSTRUMENTS
Fuellevelgauge
Thefuellevelgaugeindicatestheleveloffuelinthefuel
tank.
NOTICE:Maintainaminimumof30%offuelinfueltank
toavoidairlock.
PTIL17COM1114AA4
Hourmeter
Thiselectronichourmeterisconnectedtothealternator.
Whenevertheengineisrunning,thehourmeterstarts
counting.Regularlymonitoringthehourmeterreading
willindicatethenumberofworkinghours(cumulative).
Thiswillfacilitatetimelymaintenance/servicingofthe
machine.
Donotdisconnectthehourmeterforanyreasons.
Neutralindicator(Green)
ThisindicatorcomesONwhenthedriveleverisinneutral
position.Enginecanbestartedonlywhenthedriveisin
neutralposition.
Batterynon-chargingindicator(Red)
Wheneverthebatteryisbeingchargedtheindicatorgoes
OFF.Duringnormaloperationtheindicatordoesnotglow,
whichindicatedthatthebatteryisbeingcharged.This
indicatorchargeswhenignitionisswitchedON(Engineis
inOFFstate)andthechargingindicatorgoesoffassoon
astheenginestarts.
Ifthebatterynon-chargingindicatorcomesONduringthe
operationofthemaintenance,switchOFFthemachine
immediatelyandndoutthereasonfornon-charging.
Parkingbrakeindicator(Red)
Parkingbrakeindicatorglowswhenparkingbrakeisen-
gaged.Parkingbrakedisengageswhenthetravelcon-
troller(FNR)isforward/reverseposition.Iftheparking
brakeisnotdisengaging,thisindicatorcomesON.Shut
offtheengineimmediately,locatethecauseandsetright
theproblem.
Rightturnsignal(Green)
ThisindicatorasheswhenthesideindicatorswitchisON
(i.e.movedtowardsleftside).
