3-CONTROLSANDINSTRUMENTS
Leftturnsignal(Green)
Thisindicatorasheswhentheleft-sideindicatorswitch
ison(i.e.movedtowardsleftside).
Hydrauliclterclogindicator(Red)
ThisindicatorcomesONwhenthehydraulicoillterclogs.
Stopthemachineoperationandreplacethelterelement.
Runningthemachineafterltercloggingwillcontaminate
thehydrauliccircuitandcancauseextensivedamageto
thehydraulicsystem.
Lowlubricationoilpressureindicator(Red)
ThisindicatorcomesONwhenthelubricationoilpressure
fallsbelowapresetlevel.ShutOfftheengineimmedi-
ately,locatethecauseandsetrighttheproblem.
Preheater(Amber)
TheindicatorlampislitwhenpreheaterisONduringcold
startingthemachine.
Airlterclogindicator(Red)
ThisindicatorcomesONwhentheairlterclogs.
Highbeam(Blue)
Thisindicatorstartstoglowwhenhighheadlightbeamis
inuse.
Lowordippedbeamindicator(Green)
Thisindicatorstartstoglowwhenlowheadlightbeamis
inuse.
Highspeedindicator(Blue)
Thisindicatorglowswhenhightravelspeedisselected
fromtwospeedswitch.
3-14
