28 Case IH 91xx, 92xx and 93xx Series SmarTrax™ Installation Manual
4. Continue turning the wheels until they move steadily and smoothly when the steering wheel is turned.
5. Access the System Diagnostic screen by selecting the MACHINE TEST option on the Machine Type screen
and turn the wheels using the Raven console.
Note: If there are issues with the SmarTrax system, turn off the machine and correct them immediately.
For additional assistance, refer to the SmarTrax and SmartSteer Calibration & Operation Manual
(P/N 016-0171-277) or contact your local Raven dealer.
Calibrate the SmarTrax System
Refer to the SmarTrax & SmartSteer Calibration and Operation Manual (P/N 016-0171-277) for instructions on
calibrating the SmarTrax system, adjusting system settings, and system operation.
