Introduction
Plate - Node Mounting 107-0172-084 1
Bracket - Hydraulic Valve Mounting 107-0171-907 1
Cable - Valve, 112”, No WAS 115-4001-134 1
Transducer - 0-3000 PSI Pressure 442-0000-086 1
Tape - 3.5” Double-Sided 332-0000-019 4
Bolt - 5/16”-18 x 7/8” 311-0052-104 4
Bolt - 5/16”-18 x 1” 311-0052-105 4
Bolt - 3/8”-16 UNC x 1/2” 311-0054-105 2
Nut - 3/8”-16 UNC Flanged, Lock 312-1001-164 5
Nut - 5/16”-16 UNC Flanged, Lock 312-1001-169 4
Washer - 5/16” Split Lock 313-1000-019 4
TABLE 1. SmarTrax Installation Kit (P/N 117-5032-006)
Picture Item Description Part Number Qty.
