CONTROLLER
3 - 52
CX EXCAVATORS
RESETTING
Altitude Compensation (pump power set)
Push the Buzzer stop switch to select PA (item selected will have a light
background)
PA: 0 = Normal Mode
PA: 1,2,3 = Low Power Mode settings
To set the low pump power mode (altitude compensation), push the Travel
mode switch to change the to 1 for low power mode or 0 for normal power
mode.
To save the data press the Work mode switch for 10 seconds. The buzzer
will to notify when 10 seconds have elapsed.
Turn the key switch off to complete the procedure.
RST MODE Hi, H
1 PA 0 0 0 0
BRK 0 0 0 0 RPM AU 0 0 0 0
L/M Not Used RPM HLD 0 0 0 0
AI 0 0 0 0 SEC OUT Not Used
