INTRODUCTION
Safetyglassforallwindows
Shock-lesscabsuspensionby4-pointuidmounting
Slidingfrontwindowwithautolock
Built-intypefull-colorLCDmonitordisplay
Membraneswitchonmonitordisplay
Windshieldwiper&washer
Floormat
PolycarbonateroofhatchandSunshade
Autoair-conditioner
Raindeector
Sunvisor
Roll-overprotectivestructure(ROPS)
TopguardOPGlevel1(inCABstructure)
TopguardOPGlevel2(additionalguard)
Operator'sseat
Lowfrequencymechanicalsuspensionwithhelicalspringsanddoubleactinghydraulicdamper.(Achieves
ISO7096incategoryEM6)
Withfollowingfeatures
ManualweightadjustmentBackrestangleadjustment
Seatheightadjustment
Adjustablepivotingarmrestslinkedtoconsoles
AdjustableheadrestRetractableseatbelt
Adjustablelumbarsupport
Controlconsolesadjustindependentlyofseat
Others
Rearviewmirror(Cabside&Rightside)
RearviewCamera
Undercarriage
Travelmotor
Variabledisplacementaxialpistonmotor
BrakeMechanicaldiscbrake
Hydraulicservicebrake
Brakevalve
Finaldrive
Planetarygearreduction
High
5.3km/h(3.3mph)(Automatictravelspeedshifting)
Travelspeeds
Low
3.2km/h(2.0mph)
DBP(Drawbarpull)339kN(76210lb)
Numberofcarrierrollers(eachside)
2
Numberoftrackrollers(eachside)
9
Numberofshoes(eachside)
50
Typeofshoe
Triplegrousershoe
Linkpitch228.6mm(9.000in)
Widthofshoe
600mm(23.622in)(S.T .D)
Grade-ability70%(35°)
Mass
Operatingmass49400kg(108908.4lb)
with3.38m(11.0892ft)Arm,2.0m³Bucket,600mm(23.622in)grousershoe,operator,lubricant,
coolantandfullfueltank
Shippingmass46900kg(103396.8lb)
Operatingmass-(operatormass[75kg(165.35lb)]+90%offuelmass+bucketmass[1950kg
(4299.01lb)]
Counterweightmass10000kg(22046lb)
Groundpressure
with3.38m(11.0892ft)Arm,2.0m³Bucket,600mm(23.622in)grousershoe
0.085MPa(12.329psi)
