INTRODUCTION
Diggingforce(with2.0m³bucket)(ISO6015)
3.38m(11.0892ft)Arm2.53m(8.3005ft)Arm
Armdiggingforce201kN(45187lb)246kN(55303lb)
Withautopowerup220kN(49458lb)269kN(60474lb)
Bucketdiggingforce247kN(55528lb)247kN(55528lb)
Withautopowerup270kN(60698lb)270kN(60698lb)
Dimensions
3.38m(11.0892ft)Arm2.53m(8.3005ft)Arm
Overalllength(withoutattachment)6450mm(253.937in)6450mm(253.937in)
Overalllength(withattachment)12090mm(475.984in)12110mm(476.772in)
Overallheight(withattachment)3650mm(143.701in)3670mm(144.488in)
Overallheight(totopofheadguard)3400mm(133.858in)3400mm(133.858in)
Overallheight(totopofguardrail)3650mm(143.701in)3650mm(143.701in)
Upperstructureoverallwidth(without
catwalks)
3060mm(120.472in)3060mm(120.472in)
Upperstructureoverallwidth(with
catwalks)
3590mm(141.339in)3590mm(141.339in)
Swing(rearend)radius3730mm(146.850in)3730mm(146.850in)
Clearanceheightunderupper
structure
1330mm(52.362in)1330mm(52.362in)
Minimumgroundclearance
535mm(21.063in)535mm(21.063in)
Wheelbase(Centertocenterof
wheels)
4400mm(173.228in)4400mm(173.228in)
Crawleroveralllength5450mm(214.567in)5450mm(214.567in)
Trackgauge
2750mm(108.268in)2750mm(108.268in)
Undercarriageoverallwidth[with
600mm(23.622in)shoes]
3350mm(131.890in)3350mm(131.890in)
Crawlertracksheight1240mm(48.819in)1240mm(48.819in)
Workingranges
3.38m(11.0892ft)Arm2.53m(8.3005ft)Arm
Boomlength
6980mm(274.803in)6980mm(274.803in)
Bucketradius
1840mm(72.441in)1840mm(72.441in)
Bucketwristaction
176°176°
MaximumreachatGRP
11750mm(462.598in)10980mm(432.283in)
Maximumreach
11970mm(471.260in)11220mm(441.732in)
Max.diggingdepth
7720mm(303.937in)6870mm(270.472in)
Max.diggingheight
11100mm(437.008in)10850mm(427.165in)
Max.dumpingheight
7690mm(302.756in)7410mm(291.732in)
