k Inputting and Editing Matrices
Pressing 1(MAT) displays the matrix editor screen. Use the matrix editor to input and edit
matrices.
• {DIM} ... {specifies the matrix dimensions (number of cells)}
• {DEL}/{DEL·A} ... deletes {a specific matrix}/{all matrices}
u Creating a Matrix
To create a matrix, you must first define its dimensions (size) in the Matrix list. Then you can
input values into the matrix.
u To specify the dimensions (size) of a matrix
Example To create a 2-row ! 3-column matrix in the area named Mat B
Highlight Mat B.
c
1(DIM)
Specify the number of rows.
cw
Specify the number of columns.
dw
w
•All of the cells of a new matrix contain the value 0.
2-8-2
Matrix Calculations
# If “Memory ERROR” remains next to the matrix
area name after you input the dimensions, it
means there is not enough free memory to create
the matrix you want.
m ! n … m (row) ! n (column) matrix
None… no matrix preset
