k Drawing a Graph from a Number Table
Description
Use the following procedure to generate a number table and then draw a graph based on the
values in the table.
Set Up
1. From the Main Menu, enter the GRPH
•
TBL Mode.
2. Make V-Window settings.
Execution
3. Store the functions.
4. Specify the table range.
5. Generate the table.
6. Select the graph type and draw it.
4(G
•
CON) ... line graph*
1
5(G
•
PLT) ... plot type graph*
1
*
2
5-7-9
Using Tables
*
1
After drawing the graph, pressing u
5(G # T) or i returns to the function
storage screen. To return to the number table
screen, press 5(TABL).
*
2
Pressing 6(g) 4(G
•
PLT) on the function
storage screen generates the number table
and plots the graph simultaneously.
