Casio ALGEBRA FX 2.0

19990401
Example Draw the graph shown below and calculate the root for Y1.
Y1 = x(x + 2)(x – 2)
Use the following V-Window settings.
Xmin = –6.3, Xmax = 6.3, Xscale = 1
Ymin = –3.1, Ymax = 3.1, Yscale = 1 (initial defaults)
Procedure
1 m GRPH
•
TBL
!K(V-Window) 1(INIT)i
3(TYPE)b(Y=)v(v+c)(v-c)w
5(DRAW)
2 4(G-SLV)b(Root)
4 e
e
Result Screen
5-11-10
Function Analysis
#When analyzing a single graph, results appear
as soon as you select an analysis function in
step 2, so step 3 is not necessary.
#Root, maximum value, minimum value, and
y-
intercept can be calculated for rectangular
coordinate graphs and inequality graphs only.
# The
y-intercept is the point where the graph
crosses the
y-axis.
…
