Casio CE-T300

PARTS PRICE LIST
CE-T300
Code No. Parts Name Specification Q'ty Price Code Rank
Europe Germany
Saudi-
Arabia
1. Main PCB block
1 10012632 PCB ASSY/E479-1 E340958*1 1 1 1 EF A
F1 30007777 FUSE 230.6 1 1 1 AE A
IC1, 9 10005721 IC/MOS SN74LV244APWR 2 2 2 AF A
IC10 21145832 IC/DRIVER TA8429H 1 1 1 AZ A
IC12, 40 10005642 IC/MOS SN74LV02APWR 2 2 2 AB A
IC15 10005659 IC/MOS SN74LV08APWR 1 1 1 AB A
IC17 20061702 LSI M66300FP-201 1 1 1 BF A
IC2 10005674 IC/MOS HD74LVC244ATELL 1 1 1 AF A
IC20 10905733 REGULATOR HA17431VLP-EL 1 1 1 AC A
IC21 10015580 LSI UPD784215GC175-8EU 1 1 1 BW A
IC22, 38 10005669 IC/MOS SN74LV139APWR 2 2 2 AD A
IC23, 39 10003984 IC/MOS SN74LV00APWR 2 2 2 AB A
IC24 10007179 IC/MOS SN74LV10APWR 1 1 1 AC A
IC27, 28 10004413 IC/MOS SN74LV32APWR 2 2 2 AB A
IC29 10007177 IC/MOS SN74LV27APWR 1 1 1 AB A
IC3, 34 10005676 IC/MOS HD74LVC245ATELL 2 2 2 AF A
IC30 10005651 IC/MOS SN74AHC1G00DCKR 1 1 1 AB A
IC31 10004414 IC/MOS SN74LV74APWR 1 1 1 AC A
IC32 10005690 IC/RESET S-80823ANNP-EDL-T2 1 1 1 AB A
IC37, 44 10005671 IC/MOS SN74LV138APWR 2 2 2 AD A
IC4, 11 10005691 IC/MOS SN74HC157APWR 2 2 2 AE A
IC41 20061691 LSI HY628100ALLG-70 1 1 1 BD A
IC43 10005678 IC/MOS HD74LVC374ATELL 1 1 1 AF A
IC45 21120820 IC HIN211CA-T 1 1 1 AT A
IC47 21120821 IC/COMPARATOR BA10393F-E2 1 1 1 AB A
IC48, 49 21120788 IC/MOS L6219DS 2 2 2 BC A
IC5, 18 10005666 IC/MOS SN74LV174PWR 2 2 2 AD A
IC50 10005655 IC/RESET S-80835ALNP-EAZ-T2 1 1 1 AB A
IC6, 7 10012943 IC/MOS SN74LV164APWR 2 2 2 AE A
IC8 10004463 LSI LH28F016SCT-L95 1 1 1 CI A
X1 24088404 LOCK/CERAMIC CSTCV12.5MTJ0C4-T 1 1 1 AD A
X2 25203445 OSCILLATOR/CRYSTAL C-002RX(M90-76) 1 1 1 AD A
D1, 3, 6 23901820 DIODE/CHIP 1SS355TE-17 3 3 3 AA B
D2, 7, 8, 11, 12 23902058 DIODE/CHIP 1SR154-400TE25 5 5 5 AB B
D5 23153125 DIODE/ZENER RD22UJN1-T1 1 1 1 AA B
FB14, 15 30008056 INDUCTOR FBMH3216HM501NT 2 2 2 AB B
FB16, 17, 25, 26 30132359 INDUCTOR BK3216-4S601-T 4 4 4 AA B
FB2-13, 22 30450028 INDUCTOR BK1608HS601-T 13 13 13 AA B
Q1, 2 22501602 TRANSISTOR 2SD1834T100 2 2 2 AB B
Q5 22501609 TRANSISTOR/DIGITAL DTD123YKT146 1 1 1 AA B
Q6 22501601 TRANSISTOR 2SC4617TLQ 1 1 1 AA B
Q7 79113038 TRANSISTOR/DIGITAL DTC114YUAT106 1 1 1 AA B
BZ1 32402089 BUZZER PKM22EPT-2001 1 1 1 AE C
C13-15 28077818 CAPACITOR/ELECTROLYTIC RV-35V101MG10-R 3 3 3 AB C
C17, 19, 21 28073626 CAPACITOR/ELECTROLYTIC RV3-10V221MF80-R 3 3 3 AB C
C2, 7 28077120 CAPACITOR/ELECTROLYTIC RV2-16V100M-R 2 2 2 AA C
C25 28077127 CAPACITOR/ELECTROLYTIC RV2-50V010M-R 1 1 1 AA C
C3, 12 28073647 CAPACITOR/ELECTROLYTIC RV2-16V101MS-R 2 2 2 AA C
C9 28077106 CAPACITOR/ELECTROLYTIC RV2-35V100M-R 1 1 1 AA C
CA1-7 28073645 CAPACITOR/MODULE MNA145A470KK 7 7 7 AA C
CN1 35405189 CONNECTOR PSB4D22FC-1 1 1 1 BM C
CN10 35019380 CONNECTOR B26B-PHDSS 1 1 1 AD C
CN11 77401610 CONNECTOR B4B-PH-SM3-TB 1 1 1 AC C
CN15 35017728 CONNECTOR B14B-PHDSS 1 1 1 AB C
CN16 10005684 CONNECTOR IMSA-9830S-40Y930 1 1 1 AI C
CN17 35802371 CONNECTOR B4P-VH 1 1 1 AB C
CN18 30007917 PLUG/D-SUB CONNECTOR ID9P33E4GX28 1 1 1 AK C
CN19 35019408 CONNECTOR B7B-ZR-SM3-TF 1 1 1 AC C
CN2 35005846 CONNECTOR 53253-0210 1 1 1 AA C
CN3 35405182 CONNECTOR B26B-PHDRS 1 1 1 AH C
CN4 35021809 CONNECTOR B3B-PH-SM3-TB 1 1 1 AC C
CN8 35019275 CONNECTOR B9B-ZR-SM3-TF 1 1 1 AD C
CN9 35405178 CONNECTOR B9B-ZR-SM3-R-TF 1 1 1 AG C
IC16, 26 36106859 SOCKET/IC DILB32P-8JK 2 2 2 AD C
R1 26523053 RESISTOR/METAL FILM ERX1ANJ5R6H 1 1 1 AA C
RA1-6, 10-16, 30, 40, 54,
27975518 RESISTOR/MODULE RAC1608-1014DJT 17 17 17 AA C
RA28, 53, 56 26601159 RESISTOR/MODULE RAC1608-4724DJT 3 3 3 AA C
RA7, 8 26601162 RESISTOR/MODULE RAC1608-4714DJT 2 2 2 AA C
RA9, 17, 19-27, 35, 39,
43-52, 58-64
26601156 RESISTOR/MODULE RAC1608-1034DJT 30 30 30 AA C
RY1 31203211 RELAY MR301-5S 1 1 1 AT C
SW1 30008096 SWITCH SKQLLD-T 1 1 1 AD C
10014177 SPACER/PCB E440986-1 1 1 1 AB C
C1, 4-6, 16, 23, 28, 29, 32,
34, 36, 38-40, 42-44, 47,
48, 55, 61, 62, 65, 68, 69,
71-74, 77, 78, 80, 82-91,
99-101, 111
28073629 CAPACITOR/CHIP TMK107F104ZZ-T 46 46 46 X
C102, 103, 109, 110 28073644 CAPACITOR/CHIP UMK212BJ104KG-T 4 4 4 X
C11, 22, 49, 50, 59, 79 28073631 CAPACITOR/CHIP UMK107CH101JZ-T 6 6 6 X
C27, 30, 31, 37, 41, 54 28073628 CAPACITOR/CHIP TMK107B103KZ-T 6 6 6 X
C33, 52, 56, 64, 67 28073627 CAPACITOR/CHIP TMK107B102KZ-T 5 5 5 X
C51, 53, 63, 66 28073634 CAPACITOR/CHIP UMK107CH331JZ-T 4 4 4 X
C75 28073633 CAPACITOR/CHIP UMK107CH150JZ-T 1 1 1 X
C76 28073632 CAPACITOR/CHIP UMK107CH120JZ-T 1 1 1 X
R11 27963353 RESISTOR/CHIP RC1608-822-J-T 1 1 1 X
R12 27963346 RESISTOR/CHIP RC1608-563-J-T 1 1 1 X
R13, 14, 49 27964718 RESISTOR/CHIP RC1608-201-J-T 3 3 3 X
Item
- 68 -
