Casio CE-T300 Service Manual

Item Code No. Parts Name Specification Q'ty Price Code Rank
Europe Germany
Saudi-
Arabia
SCREW 3X8 ZMC-3 2 2 2 X
SCREW 3X8 ZMC-3 2 2 2 X
SCREW 3X5 ZMC-3 2 2 2 X
SCREW 3X8 ZMC-3 1 1 1 X
JPB 37180035 WIRE/J IPS-1009-2 2 2 2 C
6. Clerk switch circuit
24088399 LED GL3EG8 5 5 AA B
34121029 SW/TACT SKHHAL 5 5 AA C
24088400 CONNECTOR HLW24R-2C7 1 1 AC C
PCB/E445-E6 E340798-1 1 1 X
55001984 SPACER/LED LH-5-7 5 5 AM C
30008089 WIRE/J UJW-B(7.5mm) 5 5 X
7. Clerk key block
38 10017700 CABLE SUB ASSY/CLERK KEY E440785B*1 1 AG C
39 34002576 SWITCH/CLERK KEY J-Y7541 1 BM C
40 CASE/KEY CLERK SW E311204A-2 1 X
62158913 CONNECTOR/FASTEN E32406-2 1 AF C
10003976 KEY SUB ASSY/CLERK E340843A*1 1 X
SCREW 2.6X8 ZMC-3 1 X
30007581 TAB/FASTEN 23031-2 1 X
55600368 TIE/INSULOCK T-18S 2 X
30304055 CORE/FERRITE L5T18X6X10 1 AC C
8. Upper case block
41 10017332 CASE/UPPER E140250A-1 1 1 1 BQ C
42 62481264 PLATE/DISPLAY E140252-3 1 1 AV B
42 62482140 PLATE/DISPLAY E140252-13 1 AV B
43 10016141 SWITCH SUB ASSY/MODE KEY E340762A*2 1 1 1 AU B
62481309 FRAME/MODE KEY SWITCH E240513-1 1 1 1 X
43081405 PCB/E475-E3-1 E340841-1 1 1 1 X
62214028 PLATE/SLIDE E411394-1 1 1 1 X
62480912 SHAFT/MODE KEY E311850A-1 1 1 1 X
62481470 SPRING/CONTACT E412058-2 1 1 1 X
35405198 CONNECTOR HLW9S-2C7 1 1 1 X
44 62481271 RIBBON COVER E140260-1 1 1 1 AI C
45 55001979 SPACER/LOCKING RSPLS-6L 2 2 2 AB C
55002010 CLIP CS-4U 1 1 1 X
51120124 SCREW 3X8 ZMC-3..... 7 7 7 X
51120132 SCREW 3X10 ZMC-3... 1 1 1 X
51120141 SCREW 3X8 ZMC-3...... 1 1 X
54400562 SCREW 3X20 ZMC-3... 2 2 2 X
SCREW 3X8 ZMC-3 1 1 1 X
9. Lower case block
46 10010822 CASE/LOWER E140254B-1 1 1 1 BV C
47 62213892 ROLLER/RP E411377-1 2 2 2 AB B
48 62481458 COVER/POW SWITCH E340757-1 1 1 1 AE C
49 10012386 PLATE/D-SUB FIXING E340774A-1 1 1 1 AE C
50 55001980 SPACER/LOCKING SPLSN-4 2 2 2 AA C
51 TERMINAL CE2 2 2 2 X
52 CHASSIS/B E140261B-1 1 1 1 X
53 GROMET B-1. 1 1 1 X
54 55001975 PAPER WINDING UNIT FR250B 1 1 1 BR C
55 55001985 BELT/TIMING BL-87A 1 1 1 AT C
56 36375227 CORE/FERRITE TFC-25-15-12 1 1 1 AW C
TAB/FASTEN 23031-2 1 1 1 X
50415279 SCREW 3X4 ZMC-3 3 3 3 X
51120124 SCREW 3X8 ZMC-3..... 3 3 3 X
51615026 SCREW 3X8 (+)... ZMC-3 10 10 10 X
51615123 SCREW 3X8 ZMC-3.(+) 1 1 1 X
INSERT/BIT SB-3001 1 1 1 X
54400224 SCREW 4X14 ZMC-3.. 3 3 3 X
54400560 SCREW 4X35 ZMC-3..... 1 1 1 X
54400569 SCREW 3X12 ZMC-3.. 2 2 2 X
CLIP CS-4U 2 2 2 X
55600368 TIE/INSULOCK T-18S 1 1 1 X
SCREW 4 1 1 1 X
SCREW 3X6 ZMC-3 2 2 2 X
SCREW 3X4 ZMC-3 1 1 1 X
SCREW 3X12 ZMC-3 2 2 2 X
SCREW 3X3 NI 1 1 1 X
WASHER 3X8X0.5 1 1 1 X
SCREW 3X5 ZMC 2 2 2 X
10. Printer block
57 10905732 PRINTER/THERMAL LTP4242B-C432 1 1 1 DG A
SCREW 2X8 NI.. 2 2 2 X
58 55001996 CUTTER/AUTO ACU2224C-A 1 1 1 CX A
59 55001997 PLATE/CUTTER FIXING OP-L4200B 1 1 1 AE C
60 SCREW 3X4ZMC-3. 4 4 4 X
61 62481492 WIRE SUB ASSY/FG E440751*1 1 1 1 AB C
62 62481812 GUIDE/PAPER E440794-1 1 1 1 AF C
SCREW 3X6 ZMC-3 2 2 2 X
63 62481822 PLATE/RECEIPT PRINTER FIXING E340756A-1 1 1 1 AM C
64 10905732 PRINTER/THERMAL LTP4242B-C432 1 1 1 DG A
65 NUT M4... 2 2 2 X
66 55001977 WHEEL/BELT PR016A 1 1 1 AC C
NUT 3 NI. 2 2 2 X
SCREW 3X4ZMC-3. 7 7 7 X
67 62481303 HOLDER/SHAFT L E440678-1 1 1 1 AF C
68 62481304 HOLDER/SHAFT R E440679-1 1 1 1 AF C
62481306 ROLLER/PAPER FEED E440682-1 1 1 1 AS C
- 71 -
