CTK-671 MIDI Implementation
Note, however, that voices that are already sounding are maintained.
Since this parameter has virtually no affect on DSP output, reverberating sound within
the DSP and the LoFi noise generator signal continue to be output, even when the
"Cancel" setting is selected.
• System Chorus
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
10 Chorus Macro Num 5 00 - 0F 02 0 - 15
Selects the System Chorus preset type.
Receipt of GM On selects Chorus3.
Operation of this type value is also linked with the following parameters, and changes
them to prescribed values.
See "6.1.1.11 Chorus Type Setting Value Table."
11 Chorus Level 7 00 - 7F 40 0 - 127
12 Chorus Rate 7 00 - 7F 03 0 - 127
13 Chorus Depth 7 00 - 7F 13 0 - 127
14 Chorus Feedback 7 00 - 7F 00 0 - 127
Sets System Chorus feedback amount.
15 Chorus Tone 7 00 - 7F 7F 0 - 127
Adjusts the System Chorus timbre.
• System Reverb
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
18 Reverb Macro Num 5 00 - 0F 04 0 - 15
Selects the System Reverb preset type.
Receipt of GM On selects Hall2.
Operation of this type value is also linked with the following parameters, and changes
them to prescribed values.
See "6.1.1.10 Reverb Type Setting Value Table."
19 Reverb Level 7 00 - 7F 40 0 - 127
1A
Reverb Time/Del Feedback 7 00 - 7F 40 0 - 127
1B Reverb ER Level 7 00 - 7F 40 0 - 127
1C Reverb Hi Damp 7 00 - 7F 40 0 - 127
1D Reverb Tone 7 00 - 7F 7F 0 - 127
• Master Equalizer
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
20 Master EQ Macro Num 5 00 - 13 00
Selects the Master EQ preset type.
Receipt of GM On selects Standard.
Operation of this type value is also linked with the following parameters, and changes
them to prescribed values.
See "6.1.1.9 Master EQ Type Setting Value Table."
21 MasEq Lo Freq 7 00 - 7F 40 0 - 2
Selects the Master EQ low-range cutoff frequency.
See the "6.1.1.12 Equalizer Low Frequency Setting Value Table."
22 MasEq Lo Gain 7 00 - 40 - 7F 40 -12 - 0 - +12
Selects the Master EQ low-range gain.
See the "6.1.1.15 Equalizer Gain Setting Value Table."
23 MasEq Mid-Lo Freq 7 00 - 7F 40 0 - 7
Selects the Master EQ mid frequency.
See the "6.1.1.13 Equalizer Low Frequency Setting Value Table."
Mixer settings, synthesizer function, DSP function and other editable parameters are
also included in this function.
The contents of this area are rewritten whenever preset data or user data is selected.
The parameters in this area are written into the user area whenever data is written into
the user data area.
3.2.2 Patch Common Parameter List
This list shows parameters that are common for each part.
3.2.2.1 System Exclusive Format
+ ---------------------+ ------------------------------------------------------------------ +
Field Value
+ ----- + ------------+ ------------------------------------------------------------------ +
01 SYSEX F0
02 MAN 44
03 MOD 11, 01
04 dev 00 to 1F, or 7F
05 act 0(IPC), 1(IPR)
06 cat Patch = 1
07 prm 00 - 7F
08 ilen 0
09 dlen bit size - 1
10 ps LSB,MSB = 00, 00
11 <index> 00
12 <data> See "2.1 Format."
13 <sum> None
14 EOX F7
+ ----- + ------------+ ------------------------------------------------------------------ +
3.2.2.2 Parameter List
• MIDI Parameter
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
00 MIDI Device ID 7 00 - 1F 10 0 - 31
This parameter sets the SysEx Device ID.
01 MIDI Global Ch 4 00 - 0F 00 1 - 16
• Tune / Mix Parameter
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
04 Master Fine Tune 8 00 - FF 80 -100 - 0 - 99cent
See the "6.1.1.7 -99 - 0 - 99 Setting Value Table."
05 Master Coarse Tune 7 28 - 58 40 -24 - 0 - 24semi
See the "6.1.1.4 -24 - 0 - 24 Setting Value Table."
08 Master Volume 7 00 - 7F 7F 0 - 127
09 Master Pan 7 00 - 7F 40 -64 - 0 - 64
See the "6.1.1.6 Pan Setting Value Table."
0A Chorus Send To Reverb 7 00 - 7F 00 0 - 127
This specifies the volume of data sent from System Chorus to System Reverb.
0B DSP Line Cancel 1 0 - 1 0 0...Normal
1...DSP Cancel
DSP Cancel corresponds to the control panel's DSP Off/On setting. Specifying "Cancel"
for this value forces disabling of DSP input for all voices, and produces sounds through
the system.
