CTK-671 MIDI Implementation
24 MasEq Mid-Lo Gain 7 00 - 40 - 7F 40 -12 - 0 - +12
Selects the Master EQ mid-range gain.
See the "6.1.1.15 Equalizer Gain Setting Value Table."
25 MasEq Mid-Hi Freq 7 00 - 7F 40 0 - 7
Selects the Master EQ mid-high frequency type.
See the "6.1.1.13 Equalizer Mid Frequency Setting Value Table."
26 MasEq Mid-Hi Gain 7 00 - 40 - 7F 40 -12 - 0 - +12
Selects the Master EQ mid-high range gain.
See the "6.1.1.15 Equalizer Gain Setting Value Table."
27 MasEq Hi Freq 7 00 - 7F 40 0 - 2
Selects the Master EQ high-range cutoff frequency.
See the "6.1.1.14 Equalizer High Frequency Setting Value Table."
28 MasEq Hi Gain 7 00 - 40 - 7F 40 -12 - 0 - +12
Selects the Master EQ high-range gain.
See the "6.1.1.15 Equalizer Gain Setting Value Table."
• DSP Patch Parameter
This block also stores values when the DSP Type or Tone is changed.
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
2C DSP Type Number 7 00 - 7F 00 0 - 99 Preset
100 - 109 User
Selects the DSP Type.
Receipt of GM On selects "014 Delay."
127 is stored when a tone-associated DSP is read into the DSP area.
2D DSP Hold 1 0 - 1 0 0...Off
1...On
2E DSP Level 7 00 - 7F 64 0 - 127
2F DSP Pan 7 00 - 7F 40 -64 - 0 - 63
See the "6.1.1.6 Pan Setting Value Table."
• DSP Type parameter
The value of this parameter is rewritten whenever the DSP Type or Tone is changed.
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
30 DSP Name A 20 0 - FFFFFFFF 556e7469 MSB is first character.
31 DSP Name B 20 0 - FFFFFFFF 746c6564 MSB is first character.
These parameters change the DSP name. One character is indicated by each byte.
32r DSP Algorithm ID 7 00 - 3F 00 0 - 63
This value is the DSP algorithm ID, which cannot be changed at the user level.
Changing the DSP Type or Tone Number causes the algorithm ID of the main DSP to
be copied automatically to this area.
See "6.1.1.16 DSP Algorithm ID Table."
33 DSP Chorus Send 7 00 - 7F 40 0 - 127
34 DSP Reverb Send 7 00 - 7F 40 0 - 127
DSP Type Independent Parameters
The eight parameters listed below are DSP User Parameters that can be set from the
control panel, while the next 16 parameters are Internal Parameters that cannot be
edited on the control panel. The range of these parameter values is 0 to 127, regardless
of the DSP algorithm. However, the parameters that are available depend on the DSP
algorithm, which means that not all User Parameters and Internal Parameters are
necessarily available as a particular DSP's parameters.
See the "DSP Parameter List" for details about parameters and their contents.
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
38 DSP User Parameter0 7 00 - 7F - 0 - 127
39 DSP User Parameter1 7 00 - 7F - 0 - 127
3A DSP User Parameter2 7 00 - 7F - 0 - 127
3B DSP User Parameter3 7 00 - 7F - 0 - 127
3C DSP User Parameter4 7 00 - 7F - 0 - 127
3D DSP User Parameter5 7 00 - 7F - 0 - 127
3E DSP User Parameter6 7 00 - 7F - 0 - 127
3F DSP User Parameter7 7 00 - 7F - 0 - 127
40 DSP Internal Param00 7 00 - 7F - 0 - 127
41 DSP Internal Param01 7 00 - 7F - 0 - 127
42 DSP Internal Param02 7 00 - 7F - 0 - 127
43 DSP Internal Param03 7 00 - 7F - 0 - 127
44 DSP Internal Param04 7 00 - 7F - 0 - 127
45 DSP Internal Param05 7 00 - 7F - 0 - 127
46 DSP Internal Param06 7 00 - 7F - 0 - 127
47 DSP Internal Param07 7 00 - 7F - 0 - 127
48 DSP Internal Param08 7 00 - 7F - 0 - 127
49 DSP Internal Param09 7 00 - 7F - 0 - 127
4A DSP Internal Param10 7 00 - 7F - 0 - 127
4B DSP Internal Param11 7 00 - 7F - 0 - 127
4C DSP Internal Param12 7 00 - 7F - 0 - 127
4D DSP Internal Param13 7 00 - 7F - 0 - 127
4E DSP Internal Param14 7 00 - 7F - 0 - 127
4F DSP Internal Param15 7 00 - 7F - 0 - 127
3.2.3 Patch Part Parameter List
This list shows parameters that are specific for each part.
3.2.3.1 System Exclusive Format
+ --------------------- + ------------------------------------------------------------------ +
Field Value
+ ----- + ------------ + ------------------------------------------------------------------ +
01 SYSEX F0
02 MAN 44
03 MOD 11, 01
04 dev 00 to 1F, or 7F
05 act 0(IPC), 1(IPR)
06 cat Patch = 1
07 prm 00 - 7F
08 ilen 0
09 dlen bit size - 1
10 ps Parameter Set Number LSB,MSB = 00, 00
11 <index> Part Number(00-0F)
12 <data> See "2.1 Format."
13 <sum> None
14 EOX F7
+ ----- + ------------ + ------------------------------------------------------------------ +
3.2.3.2 Parameter List
• Basic parameter
ParamID Parameter bit Value Default Setting Value (Decimal)
--------------------------------------------------------------------------------------------------------------------
50 Tone Number E 000 - 189 Tone Number
This value is the tone number allocated to this part.
