CTK-671 MIDI Implementation
Format: BnH 63H vvH
n: MIDI Channel Number
vv: Value
1.2.20.1 Filter Cutoff
Format: BnH 62H 20H 63H 01H 06H mmH 26H **H
n: MIDI Channel Number
mm: Value
For information about the relationship between setting values and receive values,
see the "6.1.1.5 -64 - 0 - 63 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: This message is never sent.
Receive: Changes Filter Cutoff.
1.2.20.2 Filter Resonance
Format: BnH 62H 21H 63H 01H 06H mmH 26H **H
n: MIDI Channel Number
mm: Value
For information about the relationship between setting values and receive values,
see the "6.1.1.5 -64 - 0 - 63 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: This message is never sent.
Receive: Changes Filter Resonance.
1.2.21 RPN
• RPN LSB
Format: BnH 64H vvH
n: MIDI Channel Number
vv: Value
• RPN MSB
Format: BnH 65H vvH
n: MIDI Channel Number
vv: Value
1.2.21.1 Pitch Bend Sensitivity
Format: BnH 64H 00H 65H 00H 06H mmH 26H **H
n: MIDI Channel Number
mm: Value 0 - 24
The setting value is the same as the value that is sent and received.
Send: This message is never sent.
Receive: Changes Pitch Bend Sensitivity.
1.2.21.2 Fine Tune
Format: BnH 64H 01H 65H 00H 06H mmH 26H llH
n: MIDI Channel Number
mm: Value MSB
ll: Value LSB
For information about the relationship between setting values and send/receive
values, see the "6.1.1.7 -99 - 0 - 99 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When Channel Fine Tune is changed.
Receive: Changes Channel Fine Tune.
1.2.21.3 Coarse Tune
Format: BnH 64H 02H 65H 00H 06H mmH 26H 00H
n: MIDI Channel Number
mm: Value
For information about the relationship between setting values and send/receive
values, see the "6.1.1.4 -24 - 0 - 24 Setting Value Table" in the section of this document
titled "6. Setting Values and Send/Receive Values."
Send: When Channel Coarse Tune is changed.
Receive: Changes Channel Coarse Tune.
1.2.21.4 Modulation Depth
Format: BnH 64H 05H 65H 00H 06H mmH 26H 00H
n: MIDI Channel Number
mm: Value
The setting value is the same as the value that is sent and received.
Send: This message is never sent.
Receive: Changes Modulation depth.
1.2.21.5 Null
Format: BnH 64H 7FH 65H 7FH
n: MIDI Channel Number
Send: This message is never sent.
Receive: Deselects RPN.
1.2.22 All Sound Off
Format: BnH 78H 00H
n: MIDI Channel Number
Send: This message is never sent.
Receive: Stops all voices that are sounding.
1.2.23 Reset All Controllers
Format: BnH 79H 00H
n: MIDI Channel Number
Send: When the song function is used.
Receive: Sets initial controller values shown below.
---------------------------------------------------------------------------------------
Message Controller Values
---------------------------------------------------------------------------------------
Control Change 01H Modulation 00H
0BH Expression 00H
40H Hold1 00H
42H Sostenuto 00H
43H Soft 00H
65H/64H RPN MSB/LSB 7FH-7FH
63H/62H NRPN MSB/LSB 7FH-7FH
Channel Pressure 00H
Pitch Bend Change 40H/00H
1.3 Mode Message
1.3.1 All Notes Off
Format: BnH 7BH 00H
n: MIDI Channel Number
