CTK-671 MIDI Implementation
+ ---------------------+ --------------------------------------------------------------------------------------+
Field Value
+ ----- + ------------+ --------------------------------------------------------------------------------------+
01 SYSEX F0
02 MAN 44
03 MOD 11, 01
04 dev 00 to 1F, or 7F
05 act 2(BDS), 3(BDR), 4(HDS), 5(HDR), 7(Control)
06 cat DSP = 9
07 prm 00 - 7F
08 ilen See "2.1 Format."
09 dlen See "2.1 Format."
10 ps Indicates the DSP number being transferred.
User DSP 01 to 10 correspond to 0064H to 006DH.
See "DSP Type Number" in the “3.2.3 Patch Part
Parameter List.”
11 <index> See "2.1 Format."
12 <data> See "2.1 Format."
13 <sum> See "2.1 Format."
14 EOX F7
+ ----- + ------------+ --------------------------------------------------------------------------------------+
4.3 Song Data
• System Exclusive Format
+ ---------------------+ --------------------------------------------------------------------------------------+
Field Value
+ ----- + ------------+ --------------------------------------------------------------------------------------+
01 SYSEX F0
02 MAN 44
03 MOD 11, 01
04 dev 00 to 1F, or 7F
05 act 2(BDS), 3(BDR), 4(HDS), 5(HDR), 7(Control)
06 cat Song = A
07 prm 00
08 ilen See "2.1 Format."
09 dlen See "2.1 Format."
10 ps Indicates the song number being transferred.
Song 0 and 1 correspond to 0000H and 0001H.
See "DSP Type Number" in the "3.2.3 Patch Part
Parameter List."
11 <index> See "2.1 Format."
12 <data> See "2.1 Format."
13 <sum> See "2.1 Format."
14 EOX F7
+ ----- + ------------+ --------------------------------------------------------------------------------------+
4.4 User Rhythm Pattern
• System Exclusive Format
+ ---------------------+ --------------------------------------------------------------------------------------+
Field Value
+ ----- + ------------+ --------------------------------------------------------------------------------------+
01 SYSEX F0
02 MAN 44
03 MOD 11, 01
04 dev 00 to 1F, or 7F
05 act 2(BDS), 3(BDR), 4(HDS), 5(HDR), 7(Control)
06 cat DSP = B
07 prm 00 - F
08 ilen See "2.1 Format."
09 dlen See "2.1 Format."
10 ps Indicates the rhythm number being transferred.
User Rhythms 01 to 04 correspond to 0000H to 0003H.
See "DSP Type Number" in the "3.2.3 Patch Part
Parameter List."
11 <index> See "2.1 Format."
12 <data> See "2.1 Format."
13 <sum> See "2.1 Format."
14 EOX F7
+ ----- + ------------+ --------------------------------------------------------------------------------------+
4.5 Registration Data
• System Exclusive Format
+ --------------------- + --------------------------------------------------------------------------------------+
Field Value
+ ----- + ------------ + --------------------------------------------------------------------------------------+
01 SYSEX F0
02 MAN 44
03 MOD 11, 01
04 dev 00 to 1F, or 7F
05 act 2(BDS), 3(BDR), 4(HDS), 5(HDR), 7(Control)
06 cat DSP = C
07 prm 00 - 7F
08 ilen See "2.1 Format."
09 dlen See "2.1 Format."
10 ps Indicates the Registration number being transferred.
Registration 0-1 to 3-4 correspond to 0000H to 000FH.
See "DSP Type Number" in the "3.2.3 Patch Part
Parameter List."
11 <index> See "2.1 Format."
12 <data> See "2.1 Format."
13 <sum> See "2.1 Format."
14 EOX F7
+ ----- + ------------ + --------------------------------------------------------------------------------------+
5. DSP Parameter List
This list shows the parameters for each of the DSP algorithms.
• U0 to U7 indicate User Parameters 0 to 7, while I00 to I15 indicate Internal Parameters
00 to 15.
• In the case of parameters for which no setting range is indicated, receipt of a value
from 0 to 127 is assigned as-is to the parameter.
Algorithm 00 (00H) : Auto Pan
• U0 Rate
• U1 Depth
Algorithm 01 (01H) : Tremolo
• U0 Rate
• U1 Depth
Algorithm 02 (02H) : 2BandEQ
• U0 Low Frequency - See the "6.1.1.12 Equalizer Low Frequency Setting Value
Table."
• U1 Low Gain - See the "6.1.1.15 Equalizer Gain Setting Value Table."
• U2 High Frequency - See the "6.1.1.14 Equalizer High Frequency Setting Value
Table."
• U3 High Gain - See the "6.1.1.15 Equalizer Gain Setting Value Table."
Algorithm 03 (03H) : 3BandEQ
• U0 Low Frequency - See the "6.1.1.12 Equalizer Low Frequency Setting Value
Table."
• U1 Low Gain - See the "6.1.1.15 Equalizer Gain Setting Value Table."
• U2 Mid Frequency - See the "6.1.1.13 Equalizer Mid Frequency Setting Value
Table."
• U3 Mid Gain - See the "6.1.1.15 Equalizer Gain Setting Value Table."
• U4 High Frequency - See the "6.1.1.14 Equalizer High Frequency Setting Value
Table."
• U5 High Gain - See the "6.1.1.15 Equalizer Gain Setting Value Table."
Algorithm 04 (04H) : LFO Wah
• U0 Input Level
• U1 Resonance
• U2 Manual
• U3 LFO Rate
• U4 LFO Depth
