E-39
Using the Ethernet Cradle (HA-F62IO/HA-F62IOA)
The optionally available Enthernet Cradle (HA-F62IO/HA-F62IOA) makes it
possible to transmit data and les between the Handheld Terminal and a PC via
a USB or LAN connection (download or upload). You can also use the Ethernet
Cradle to charge the battery pack installed in the Handheld Terminal.
General Guide
Details common to both HA-F60IO and HA-F60IOA are shown in the HA-F60IO
illustrations.
Top
11
9
10
Left
4
Right (HA-F62IOA)
3
Front (HA-F62IO)
12
Front (HA-F62IOA)
12
13
Back
6
7
8
5 2 1
