8
The numbers in parentheses indicate the pages where each item is explained.
• Above illustration shows the camera’s cover removed (page 18).
General Guide
1
Frame (page 13)
2
Shutter button (page 31)
3
[HDMI] cover (page 68)
4
LED light (page 57)
5
Lens
6
Microphone
(pages 16, 49)
7
[HDMI] HDMI output
(micro) (page 68)
8
[USB] port
(pages 19, 22, 92, 96)
9
[p] (Power) (page 29)
bk
Back lamp
(pages 20, 23, 29, 31)
bl
Strap hole (page 8)
bm
Monitor screen
(pages 9, 9, 16, 100)
bn
Speaker
8
2
7
4
5
6
1 3
9
bk
bl
bm
bn
bo
bp
bq
bo
Battery compartment (page 18)
bp
Memory card slot (pages 27, 122)
bq
[OPEN] button (pages 18, 27)
1
2
To attach the strap (commercially available or
separately available) to the camera
Attach strap here.
