Casio EXILIM EX-Z550 User Manual

40
Snapshot Tutorial
Using Focus Lock
“Focus lock” is a technique you can use when you want to
compose an image in which the subject you want to focus
on is not within the focus frame in the center of the
screen.
• To use focus lock, select “Û Spot” for the Auto Focus
area (page 41).
1. Align the monitor screen’s focus frame with
the subject you want to focus on and then half-
press the shutter button.
2. Keeping the shutter button half-pressed (which
maintains the focus setting), move the camera
to compose the image.
3. When you are ready to shoot the image, press
the shutter button the rest of the way down.
NOTE
• Focus lock also locks exposure (AE).
Subject to be focused on
Focus frame

Casio EXILIM EX-Z550 Specifications

General

Megapixel	14.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.3 \
Maximum image resolution	4320 x 3240 pixels
Digital zoom	4 x
Combined zoom	16 x
Lens structure (elements/groups)	7/6
Interface	USB/AV
Digital SLR	No
Camera shutter speed	1/2 - 1/2000 s
Focal length (35mm film equivalent)	26 - 104 mm
Auto focusing (AF) modes	multi point auto focus, spot auto focus
Macro focusing range (wide)	0.05 - 0.50 m
Manual focusing range (wide)	0.15 - ∞ m
Auto Mode focusing range (wide)	0.12 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	64, 100, 200, 400, 800, 1600, 3200, Auto
Light exposure control	Program AE
Flash modes	auto, Flash off, Red-eye reduction
Flash range (tele)	0.6 - 2.5 m
Flash range (wide)	0.15 - 5.8 m
Motion JPEG frame rate	24 fps
Video formats supported	AVI
Maximum video resolution	1280 x 720 pixels
Display diagonal	2.7 \
Display resolution (numeric)	230400 pixels
USB version	2.0
Product color	Red
White balance	auto, daylight, manual, Shade, Tungsten
Battery type	NP-80
Number of batteries supported	1
Cables included	AV, USB
Compatible memory cards	microdrive, sd, sdhc
Camera shutter type	electronic, mechanical

Weight and Dimensions

Depth	22.4 mm
Width	99.5 mm
Height	55.4 mm
Weight	137 g
