13.3.7 mem : Memory Area ID
Format: 0mmmmmmmB
Specifies the memory area that is the object of the parameter transfer. The following are defined for
this Instrument. Instrument-specific System Exclusive messages basically correspond to the user area
only.
mem Data Type Meaning
1 User area Read/write enabled
13.3.8 pset : Parameter Set Number
Format: LSB 0nnnnnnnB
MSB 0mmmmmmmB
This field is a 2-byte (LSB, MSB) value indicating the number of the parameter set (mmmmmmmnnnnnnnB,
Binary) being transferred.
13.3.9 blk Block Number
The block number is a supplementary number that specifies which block parameter is to be accessed
when there are multiple blocks (instrument parts, etc.) that include parameters with the same ID within
a single parameter set. The array structure of a block can be expressed up to 4 dimensions, and the size
of a 1-dimensional array is expressed as 14 bits.
Format: index3 LSB 0iiiiiiiB
index3 MSB 0jjjjjjjB
index2 LSB 0kkkkkkkB
index2 MSB 0lllllllB
index1 LSB 0mmmmmmmB
index1 MSB 0nnnnnnnB
index0 LSB 0oooooooB
index0 MSB 0pppppppB
Note: Arranged in high dimension sequence.
1-dimension array block [index0]
1-dimension array block [index0]
Value Meaning
00jjjjjjjiiiiiiiB 0000H
00lllllllkkkkkkkB 0000H
00nnnnnnnmmmmmmmB 0000H
00pppppppoooooooB index0
