Parameter ID R/W Block Size Array Min-Def-Max Description
Chorus Send 000B R/W 6-0:Key # 7 01 00-00-7F 0 - 127
Reverb Send 000C R/W ↑ 7 01 00-28-7F 0 - 127
Delay Send 000D R/W ↑ 7 01 00-00-7F 0 - 127
DSP On/Off 000E R/W ↑ 1 01 00-01-01 0...Off
1...On
20 Hex Layer Parameter
These parameters configure hex layer tone settings.
20.1 Hex Layer Parameter
These parameters configure basic hex layer tone settings.
Parameter ID R/W Block Size Array Min-Def-Max Description
Volume 002D R/W 55-0:0 7 01 00-64-7F 0 - 127
Detune 002E R/W ↑ 5 01 00-00-1F 0 - 31
Pitch Lock 002F R/W ↑ 1 03 00-00-01 0...Unlocked
1...Locked
Mode 0030 R/W ↑ 2 01 00-00-02 0...Normal Mode
1...Mono Mode
2...Bass Synth Mode
20.2 Hex Layer LFO Parameter
These parameters configure hex layer tone LFO settings.
Parameter ID R/W Block Size Array Min-Def-Max Description
20.3 Hex Layer Tone Edit Parameter (x6layer)
These are hex layer tone editing parameters.
20.3.1 Basic Parameter
These are hex layer tone editing basic parameters.
Parameter ID R/W Block Size Array Min-Def-Max Description
Layer On/Off 0000 R/W 2-0:Layer # 1 01 00-01-01 0...Off
1...On
Start Trigger 0003 R/W ↑ 1 01 00-00-01 0...Key On
1...Key Off
Key Range Low 0004 R/W ↑ 7 01 00-00-7F 0 - 127
Key Range High 0005 R/W ↑ 7 01 00-7F-7F 0 - 127
Velocity Range Low 0006 R/W ↑ 7 01 00-00-7F 0 - 127
Velocity Range High 0007 R/W ↑ 7 01 00-7F-7F 0 - 127
20.3.2 Pitch Parameter
These are hex layer tone editing pitch parameters.
Parameter ID R/W Block Size Array Min-Def-Max Description
Coarse Tune 000F R/W 2-0:Layer # 7 01 00-40-7F Added to key number as 0x40 center.
Fine Tune 0010 R/W 16 01 0000-0000-FFFF S------.- -------- S:sign bit
-------.c cccccccc c:cent
= 100/512cent resolution
0000000.1 00000000...For +50 cent
1111111.1 00000000...For -50 cent
36
