Casio Privia PX-160 User Manual

English
Playing with Different Tones
EN-13
Changing the Octaves of the duet
keyboards
You can change the ranges of the left and right
keyboards in octave units from their initial default
settings. This comes in handy, for example, if the initial
default range is not enough when one person is
playing the left hand part and another person is
playing the right hand part.
1. While holding down the FUNCTION and
METRONOME buttons, press the keyboard C
key that you want located at C4 (middle C) of
the left keyboard. Keep FUNCTION and
METRONOME depressed as you advance to
step 2, below.
Example: Press the keyboard key of the leftmost C (C4)
will assign the range shown below.
2. While still holding down the FUNCTION and
METRONOME buttons, press the keyboard C
key that you want located at C4 (middle C) of
the right keyboard.
NOTE
• You can return the keyboards to their initial default
ranges by exiting and then re-entering the Duet
Mode.
C4 C5 C6 C7 C3 C4 C5 C6
Left keyboard Right keyboard
(Pressed key)
1 octave higher than initial
setting
Unchanged
PX160-ES-1B.indd 15 2016/01/20 17:58:31

Casio Privia PX-160 Specifications

General

Keyboard	88 keys, Tri-sensor Scaled Hammer Action Keyboard II
Touch Response	3 sensitivity levels, Off
Polyphony	128 notes
Tones	18 built-in tones
Recorder	2 tracks, 1 song
Duet Mode	Yes
Power Supply	AC Adapter: AD-A12150LW
Sound Source	AiR Sound Source
Digital Effects	Reverb (4 types), Chorus (4 types), Brilliance
Recorder Capacity	Approximately 5, 000 notes
Pedals	SP-3 pedal included, optional 3-pedal unit
Speakers	2 x 8W
Dimensions	1, 322 x 293 x 141 mm (without music stand)
Weight	11.1 kg (without music stand)
Included Accessories	AC Adapter (AD-A12150LW), Music Stand, Pedal (SP-3)
Connections	Headphones (Stereo mini jack) x 2, LINE OUT (L/MONO, R), USB port, Pedal connector
Key Transpose	-12 to 0 to +12 semitones
Tuning Control	A4 = 415.5 Hz ～ 440.0 Hz ～ 465.9 Hz
Metronome	Beats: 0 (Tempo range: quarter note = 20 to 255)
