Casio PX-130 User Manual

– 18 –
Removing the KY-ASSY

Remove all three screws from either side case (S-CASE-IL and S-CASE-IR), and then remove both 1.
side cases.
Remove 26 screws on the bottom of the main unit.2.
Remove three screws and then the KY-ASSY.3.
KY-ASSY

Casio PX-130 Specifications

General

Polyphony	128 notes
Tones	16 built-in tones
Speakers	2 x 8W
Amplifier Output	8W + 8W
MIDI	Yes
USB	Yes
Touch Response	3 sensitivity levels, Off
Lesson Function	Yes
Recorder	2 tracks, 1 song
Metronome	Yes
Pedals	Included SP-3
Power Consumption	18W
Keyboard	88-key, Scaled Hammer Action
Weight	11.2 kg
Digital Effects	Reverb (4 types)
Built-in Songs	60 songs
Terminals	USB, Pedal
Power Requirements	AC adaptor AD-A12150LW
Touch Sensitivity	3 levels, off
Transpose	25 steps (-12 to +12 semitones)
Connectors	USB, Pedal
Power Supply	AC adaptor AD-A12150LW
Included Accessories	Music stand
Recorder Capacity	Approximately 5, 000 notes
Tuning	A4 = 415.5Hz to 465.9Hz
