Casio PX-130 User Manual

– 19 –

Removing the keys
<Removing the keys>
To remove the keys, you will need two of the tools described below.
Before removing a black key, you must rst remove both white keys on either side of the black key.
White keys may be removed with the same procedures as removing black keys.
<Tool>
The tool used in the photos in this section was converted from a gardening ID tag. The size and shape
of an ID tag accord to the dimensions below.
<Note on shaping an ID tag>
The thickness of the tool must be within 1.2~1.3 mm.
If the tool is too thin, removing keys become difcult.
If the tool is too thick, it may damage the rib of the chassis.
<Tool dimensions>
Width:
15~20 mm
R=2.75 mm
Use this part to
remove the key.
7 mm
Thickness:
within 1.2~1.3 mm

Casio PX-130 Specifications

General

Polyphony	128 notes
Tones	16 built-in tones
Speakers	2 x 8W
Amplifier Output	8W + 8W
MIDI	Yes
USB	Yes
Touch Response	3 sensitivity levels, Off
Lesson Function	Yes
Recorder	2 tracks, 1 song
Metronome	Yes
Pedals	Included SP-3
Power Consumption	18W
Keyboard	88-key, Scaled Hammer Action
Weight	11.2 kg
Digital Effects	Reverb (4 types)
Built-in Songs	60 songs
Terminals	USB, Pedal
Power Requirements	AC adaptor AD-A12150LW
Touch Sensitivity	3 levels, off
Transpose	25 steps (-12 to +12 semitones)
Connectors	USB, Pedal
Power Supply	AC adaptor AD-A12150LW
Included Accessories	Music stand
Recorder Capacity	Approximately 5, 000 notes
Tuning	A4 = 415.5Hz to 465.9Hz
