Casio PX-130 User Manual

– 42 –
1: PX-130BK_DI
2: PX-130BK_EU
3: PX-130BK_UK
4: PX-130BK_US
5: PX-130WE_DI
6: PX-130WE_EU
7: PX-130WE_UK
8: PX-130WE_US
9: PX-130RD_DI
10: PX-130RD_EU
11: PX-130RD_UK
12: PX-130RD_US
1: PX-130BK_DI
2: PX-130BK_EU
3: PX-130BK_UK
4: PX-130BK_US
5: PX-130WE_DI
6: PX-130WE_EU
7: PX-130WE_UK
8: PX-130WE_US
9: PX-130RD_DI
10: PX-130RD_EU
11: PX-130RD_UK
12: PX-130RD_US
123456789 10 11 12
MAIN PCB (MDA1)
N 1 10340876 PCB ASSY/MAIN TK-RJM509830*001 111111111111 B MDA1 PCB
2 69261580 SPONGE/35X150 M440499-1 111111111111 B
N CN9 10257512 CONNECTOR UBR23-4K5G00 111111111111 C USB jack
IC13 10256338 IC CS4351-CZZR 111111111111 C
IC1 10241413 IC R1151N001C-TR-F 111111111111 C
IC12 10197808 IC TC7SZ08FU(TE85L.F) 111111111111 C
IC4 10197554 IC TC7SZ126FU(TE85L.F 111111111111 C
IC5 10255468 LSI MB91F036PFF-GE1 111111111111 C
N IC14 10333782 LSI UPD65943GK-F659EUA 111111111111 C
N IC2 10333111 MEMORY MD56V82160-6TAZ03B 111111111111 C
N IC6 10333112 MEMORY S29GL256P90TFCR20D 111111111111 C
L39 10193074 COIL DLW21HN181SQ2L 111111111111 X
Q1,Q2,Q3,Q8 69409403 TRANSISTOR 2SA1576AT106R 444444444444 X
Q7 22592764 TRANSISTOR 2SB1188T100Q 111111111111 X
Q4,Q5,Q6 69300298 TRANSISTOR 2SC4081T106R 333333333333 X
X1,X31 10334293 RESONATOR 9C12000163 222222222222 X
SUB PCB (PSA1)
N 3 10340877 PCB ASSY/PSA1 TK-RJM509831*001 111111111111 C PSA1 PCB
IC203 10201503 IC PQ1CG21H2FZH 111111111111 C
IC202 10306512 IC TDA7297 111111111111 C
J204 10206815 CONNECTOR JY-6314*01-030 111111111111 B Damper pedal jack
N J202 10334294 CONNECTOR KM02022ABMP 111111111111 A DC jack
L202-L204,
L206
10231920 COIL RB53-856397NP 444444444444 X
L205 10232457 COIL RII7-860400NP 111111111111 X
N D204 10334295 DIODE LUDZS12BT1G 111111111111 X
N D202 10334296 DIODE LUDZS8.2BT1G 111111111111 X
D203 10210387 DIODE RSX101VA-30TR 111111111111 X
D201 10294394 DIODE SK34A 111111111111 X
FU201 10238345 FUSE 25H0500G 111111111111 C
IC201 10306415 IC BH3547F-E2 111111111111 C
Q201-Q209 69300298 TRANSISTOR 2SC4081T106R 999999999999 X
Specification
Price
Code
R Remarks
Q'ty
N Item Code No. Parts Name

Casio PX-130 Specifications

General

Polyphony	128 notes
Tones	16 built-in tones
Speakers	2 x 8W
Amplifier Output	8W + 8W
MIDI	Yes
USB	Yes
Touch Response	3 sensitivity levels, Off
Lesson Function	Yes
Recorder	2 tracks, 1 song
Metronome	Yes
Pedals	Included SP-3
Power Consumption	18W
Keyboard	88-key, Scaled Hammer Action
Weight	11.2 kg
Digital Effects	Reverb (4 types)
Built-in Songs	60 songs
Terminals	USB, Pedal
Power Requirements	AC adaptor AD-A12150LW
Touch Sensitivity	3 levels, off
Transpose	25 steps (-12 to +12 semitones)
Connectors	USB, Pedal
Power Supply	AC adaptor AD-A12150LW
Included Accessories	Music stand
Recorder Capacity	Approximately 5, 000 notes
Tuning	A4 = 415.5Hz to 465.9Hz
