Casio PX-130 User Manual

– 43 –
1: PX-130BK_DI
2: PX-130BK_EU
3: PX-130BK_UK
4: PX-130BK_US
5: PX-130WE_DI
6: PX-130WE_EU
7: PX-130WE_UK
8: PX-130WE_US
9: PX-130RD_DI
10: PX-130RD_EU
11: PX-130RD_UK
12: PX-130RD_US
123456789 10 11 12
Specification
Price
Code
R Remarks
Q'ty
N Item Code No. Parts Name
CONSOLE PCB (CNA1)
N 4 10340879 PCB ASSY/CNA1 TK-RJM509832*001 111111111111 X CNA1 PCB
N D603-D609 10336974 LED 26-21/R1 777777777777 X
N D602 10336975 LED 26-21/Y1 111111111111 X
N SW601-SW607 10337110 SWITCH TP-1138A-10-100GF 777777777777 C
CONSOLE PCB (CNA2)
N 5 10340878 PCB ASSY/CNA2 TK-RJM509833*001 111111111111 C CNA2 PCB
VR601 10123103 VARIABLE RESISTOR RK09K12C0D1B 111111111111 B Main volume
KEYBOARD ASSY
N 6 10340880 PCB ASSY/KEY TK-RJM509609*001 111111111111 C KYC & KYD PCBs
D601-D628,
D801-D818
10301580 DIODE LM1MA142WAT1G 46 46 46 46 46 46 46 46 46 46 46 46 X
7 10336109 CABLE UL2896-20-280-MACP 111111111111 X
8 10334298 FABRIC TAPE/15X270 M411937-001V01 111111111111 X
N 9 10355627 RUBBER CONTACT/AG1 RJM509219-002V02 777777777777 A
N 10 10355628 RUBBER CONTACT/GC1 RJM509220-002V02 111111111111 A
11 10341198 PCB ASSY/KYA TK-RJM509622*001 111111111111 C KYA PCBs
D601-D644 10294400 DIODE LM1MA142WKT1G 44 44 44 44 44 44 44 44 44 44 44 44 X
12 10341199 PCB ASSY/KYB TK-RJM509624*001 111111111111 C KYB PCBs
D801-D844 10294400 DIODE LM1MA142WKT1G 44 44 44 44 44 44 44 44 44 44 44 44 X
13 10336111 CABLE UL2896-20-120-MACP 111111111111 X
14 10336108 CABLE UL2896-30-265-MACP 111111111111 X
N 15 10164446 FABRIC TAPE20X120 RJM502073-002V01 222222222222 X
N 16 10334331 RUBBER CONTACT/AG2 RJM509217-001V01 777777777777 A
N 17 10334332 RUBBER CONTACT/GC2 RJM509218-001V01 111111111111 A
18 10284644 BLACK KEY RJM502797-001V01 36 36 36 36 36 36 36 36 36 36 36 36 A
19 10284645 WHITE KEY/CEGB RJM502862-001V03 777777777777 A
20 10284646 WHITE KEY/DFA RJM502863-001V03 777777777777 A
21 10151960 WHITE KEY/B RJM502794-001V02 111111111111 A
N 22 10337003 WHITE KEY/SA RJM502795-003V03 111111111111 A
N 23 10337004 WHITE KEY/SC RJM502796-003V03 111111111111 A
N 24 10341062 HAMMER ASSY/W1 TK-RJM509600*001 13 13 13 13 13 13 13 13 13 13 13 13 C
N 25 10341063 HAMMER ASSY/W2 TK-RJM509601*001 13 13 13 13 13 13 13 13 13 13 13 13 C
N 26 10341064 HAMMER ASSY/W3 TK-RJM509602*001 13 13 13 13 13 13 13 13 13 13 13 13 C
N 27 10341065 HAMMER ASSY/W4 TK-RJM509603*001 13 13 13 13 13 13 13 13 13 13 13 13 C

Casio PX-130 Specifications

General

Polyphony	128 notes
Tones	16 built-in tones
Speakers	2 x 8W
Amplifier Output	8W + 8W
MIDI	Yes
USB	Yes
Touch Response	3 sensitivity levels, Off
Lesson Function	Yes
Recorder	2 tracks, 1 song
Metronome	Yes
Pedals	Included SP-3
Power Consumption	18W
Keyboard	88-key, Scaled Hammer Action
Weight	11.2 kg
Digital Effects	Reverb (4 types)
Built-in Songs	60 songs
Terminals	USB, Pedal
Power Requirements	AC adaptor AD-A12150LW
Touch Sensitivity	3 levels, off
Transpose	25 steps (-12 to +12 semitones)
Connectors	USB, Pedal
Power Supply	AC adaptor AD-A12150LW
Included Accessories	Music stand
Recorder Capacity	Approximately 5, 000 notes
Tuning	A4 = 415.5Hz to 465.9Hz
