Casio PX-330BK User Manual

– 26 –

Removing the tweeter
1. Undo two screws and then remove the tweeter.
2. Similarly remove the other tweeter.
<Caution when replacing with a new part>
To attach sponge to the cable to the tweeter, refer to the illustration below for its position.
LEFT
RIGHT
20 ± 5 mm
20 ± 5 mm 20 ± 5 mm

Casio PX-330BK Specifications

General

Brand	Casio
Model	PX-330BK
Category	Electronic Keyboard
Language	English
