– 27 –

Removing the speaker
1. Undo three screws.
2. Remove two hooks and then the speaker cover.
3. Undo four screws and then remove the speaker.
4. Similarly remove the other speaker.
<Caution when replacing with a new part>
To attach sponge to the cable to the speaker, refer to the illustration below for its position.
Hooks
Speaker cover
LEFT
RIGHT
60 ± 10 mm
50 ± 10 mm
