Casio PX-330BK - Keyboard Assembly Component Removal

– 28 –

Removing the KY-ASSY
1. Undo all three screws from either side case (S-CASE-IL and S-CASE-IR), and then remove both side
cases.
2. Undo 26 screws on the bottom of the main unit.
3. Place the main unit with the keys facing up.
4. Undo three screws and then remove the KY-ASSY.
KY-ASSY
