Casio PX-760 User Manual

A single session is concluded only when this Instrument returns an IPS (Individual Parameter Send)
in response to an IPR (Individual Parameter Request) from an external device, or when an external
device or this Instrument spontaneously sends an IPS. If this Instrument received an IPS, the value of
the applicable parameter is changed.
Depending on the function of a parameter, Individual Parameter Send may be used to issue a com-
mand to the Instrument or Individual Parameter Request may be used to check Instrument status
information.
16.1 Two-way Communication
16.1.1 Example : Data send in response to send request to the Instrument
Data Receiver Data Sender Operation
IPR -----> Send Request
<----- IPS Data Transfer
16.2 One-way Communication
16.2.1 Example : Data send to Instrument from external source
Data Sender Data Receiver Operation
-----> IPS Data Transfer
16.2.2 Example : Data send resulting from Instrument operation
Data Receiver Data Sender Operation
<----- IPS Data Transfer
34

Casio PX-760 Specifications

General

Keyboard	88 keys, Tri-sensor Scaled Hammer Action Keyboard II
Sound Source	Multi-dimensional Morphing AiR
Polyphony	128 notes
Tones	18 built-in tones
Reverb	4 types
Chorus	4 types
Brilliance	Yes
DSP	Yes (Preset for some tones)
Touch Response	3 sensitivity levels, Off
Lesson Function	Part on/off
Recorder	2 tracks, 1 song
Pedals	3 pedals (damper, soft, sostenuto)
Tuning Control	A4 = 415.5Hz ~ 440.0Hz ~ 465.9Hz
Speakers	12cm x 2
Amplifier Output	8W + 8W
Key Transpose	25 steps (-12 semitones to +12 semitones)
Connections	Headphones (Standard stereo jack)
Power Supply	AC adaptor: AD-A12150LW
Weight	31.5 kg
Metronome	Beats: 0, 2, 3, 4, 5, 6 (Tempo range: quarter note = 20 to 255)
