Casio PX-760 User Manual

20 Tone Parameters
20.1 Basic Parameters
Parameter ID R/W Block Size Array Min-Def-Max Description
Name 0000 R/W 000000 7 10 00-20-7F Ascii Character
Timbre Type 0001 R/W ↑ 4 01 00-00-0F 0...Melody
1...Piano
2...Drum
3...reserved
4...LM Piano
Timbre Num 0002 R/W ↑ 14 01 0000-0000-3FFF 0-16383
Oct Shift 0003 R/W ↑ 3 01 02-04-06 -2 - 0 - +2
Line Select 0004 R/W ↑ 1 01 00-00-01 0...Direct
1...DSP
Level 0005 R/W ↑ 7 01 00-7F-7F 0-127
Touch Sens 0006 R/W ↑ 7 01 00-7F-7F -64 - 0 - +63
Tva Keyoff Touch Tbl 0007 R/W ↑ 7 01 00-02-7F
Tva Rate Keyoff Depth 0008 R/W ↑ 7 01 00-7F-7F -64 - 0 - +63
Tvf Keyoff Touch Tbl 0009 R/W ↑ 7 01 00-02-7F
Tvf Rate Keyoff Depth 000A R/W ↑ 7 01 00-7F-7F -64 - 0 - +63
Kff Keyoff Touch Tbl 000B R/W ↑ 7 01 00-02-7F
Kff Rate Keyoff Depth 000C R/W ↑ 7 01 00-7F-7F -64 - 0 - +63
Sys Fx Send Override 000D R/W ↑ 1 01 00-00-01 0...No (Note1)
1...Yes
Cho Normal Send 000E R/W ↑ 7 01 00-00-7F 0-127
Cho Deep Send 000F R/W ↑ 7 01 00-00-7F 0-127
Rev Send 0010 R/W ↑ 7 01 00-28-7F 0-127
Note1 : When a tone is selected whose Sys Fx Send Override parameter setting is  Yes , the send level setting value to
the System Chorus and System Reverb of the part assigned to this tone is rewritten to the value that is stored by this tone.
38

Casio PX-760 Specifications

General

Keyboard	88 keys, Tri-sensor Scaled Hammer Action Keyboard II
Sound Source	Multi-dimensional Morphing AiR
Polyphony	128 notes
Tones	18 built-in tones
Reverb	4 types
Chorus	4 types
Brilliance	Yes
DSP	Yes (Preset for some tones)
Touch Response	3 sensitivity levels, Off
Lesson Function	Part on/off
Recorder	2 tracks, 1 song
Pedals	3 pedals (damper, soft, sostenuto)
Tuning Control	A4 = 415.5Hz ~ 440.0Hz ~ 465.9Hz
Speakers	12cm x 2
Amplifier Output	8W + 8W
Key Transpose	25 steps (-12 semitones to +12 semitones)
Connections	Headphones (Standard stereo jack)
Power Supply	AC adaptor: AD-A12150LW
Weight	31.5 kg
Metronome	Beats: 0, 2, 3, 4, 5, 6 (Tempo range: quarter note = 20 to 255)
