– 82 –
10-5. Afxing the Plastic sheets on the Battery Pack
TAPE/BATTERY A
TAPE/BATTERY B
TAPE/BATTERY C
Completed image of affixing the
plastic sheets
Afxingstandard:Alignthesheetwiththeratingplates.
*Thesheetshouldnotstickoutfromtheratingplates.
Afxingstandard:
Centerofthegroove.
Payattentiontotheverticaldirectionofthesheets<onbothsides>.
Bendthesheetsasshowninthegure,andafx
themtightly<sameontheotherside>.
Donotcovertheterminals.
Afxingstandard: Wheretheupperandthelowercasejointogether<sameontheotherside>.
NG
Battery
OK
Thethickpartofthesheetshouldstaywithinthehorizontallengthof
thebatterypack.
