— 27
—
A-6. Secure it with 17 screws.
NOTE
:
T
ighten the screws in the order of the numbers indicated in the illustration below
.
1
1
1
3
9
15
8
6
14
13
5
7
16
10
4
2
12
17
A-7. Engage the COM Chassis and the Main PCB, and then secure them with five screws.
Screws (S5)
29
31
