— 104 —
MCR (2-TRACK) UNIT
Item Code No. Parts Name Specification Q R
112 1904 8772 PCB/MCR CONTROL EAL-0328 00400910 1 C
U1.3 1904 8773 LSI UPD71051C 00500740 2 A
U5.6 1904 8774 IC/MOS TC74HC14AP 00606290 2 A
C7 CAPACITOR/ELECTROLYTIC 10uF 16V 01200868 1 X
C1.3.4-6.8 CAPACITOR/CERAMIC 0.1uF 50V 01102010 7 X
R1.3 RESISTOR 25SJ 100Kohm 10601250 3 X
RP1 RESISTOR/ARRAY 100Kx6 01700145 1 X
CN1 1904 8775 CONNECTOR 53047-1210 03202140 1 C
CN2 1904 8776 CONNECTOR BTK24S-2S 03200710 1 C
51 1904 8777 MCR UNIT ZU-M1242S1 60700650 1 A
83 1904 8778 HARNESS ASSY EAA-2508A 47411031 1 C
To Next Page
