— 7 —
2. SPECIFICATIONS
2-1. SA-5000 / 5100 unit
Environment and Safety Specifications
Specifications
Operating Temperature 5˚C — 35˚C
Operating Humidity 20% to 90% Non Cond. RH
Storage Temperature -10˚C — 80˚C
EMI FCC Class A
CE Mark
Safety & ESD cUL1950, GS
CE Mark
Power Supply 110VAC, 60Hz, 165W
220VAC, 50Hz, 165W
2-2. SA-5001C / SA-5002M (Operator LCD Display)
Model LCD Name LCD Life time Remark
SA-5001M LM64183P 10,000 hours or more Monochrome
SA-5002C LM64C55 10,000 hours or more Color
Note : Life time conditions
Operating tempurature : 25 ±5°C (Monochrome), 25 ±1°C (Color)
Brightness value : Became 50% of the initial value
2-3. HDD
Model MTBF
ST3850A 300,000 hours or 40,000 contacts
2-4. FDD
Model MTBF Device life
MF355F-3 80,000 hours 5 years or 20,000 hours
2-5. MCR (2 track)
Model MTBF
ZU-M1241S1 300,000 pass
To Next Page
