3. OPTION LIST
Device Product Name Description
Operator display SA-5001M 9.4 inch Monochrome LCD display
SA-5002C 10.4 inch Color LCD display
Customer display SA-5060N 1x11 Numeric display
SA-5061D 2x20 Alpha display (5.5mm hight )
SA-5062DH 2x20 Alpha display (10.5mm hight)
Second Drawer M-sized drawer with open sensor
Magnetic Card Reader SA-5040MCR 3 track reader
4. OPTION INSTALLATION
4-1. Operator LCD display (SA-5001M, SA-5002C)
Note : Make sure that the power switch is turned off.
LCD Display
(Top Assembly)
Neck
Power Cable
Power Cable
System Assembly
Signal Cables
Mono : one cable
(
Colour : two cable
Signal Cables
Installing LCD Display to System
To Next Page
