— 110 —
POWER SUPPLY BLOCK
Item Code No. Parts Name Specification Q R
60 INLET JR-101S 20300510 1 X
61 1904 8580 SWITCH/POWER SJ-WZH4A-03BB2 20200115 1 C
94-1 1904 8581 HARNESS ASSY EAA-2492D 47410937 1 C
94-2 1904 8582 HARNESS ASSY EAA-2493A 47410938 1 C
94-3 1904 8583 HARNESS ASSY EAA-2648 47411200 1 C
52 1904 8584 POWER SUPPLY UNIT KCM150-51C 20100010 1 A
97 WIRE ULH1672 AWG22 WHITE L=330 20500380 1 X
TUBE ø5 L=20 55700610 3 X
TUBE ø4 L=20 55700600 4 X
CABLE ASSY
Item Code No. Parts Name Specification Q R
84 1904 8585 CABLE EAA-2497 47410950 1 C
85 1904 8586 CABLE EAA-2498 47410960 1 C
93 1904 8587 CABLE/DIN CONNECTOR EAA-2799A 47410970 1 C
89 1904 8588 CABLE/LCD EAH-0055 47413169 1 C
1904 8717 SHIELD/SHRINK 30mmX320L 55700350 1 X
96 1904 8589 VFD(2X20) CABLE ASSY EAA-2531A RELAY CABLE 47411050 1 C
CLAMP/FEERITE ZCAT1518-0730 21002000 1 X
INSULOCK TIE (comes with the obove part) 1 X
88 1904 8590 CABLE/BACK LIGHT EAA-2534B RELAY CABLE 47411052 1 C
91 1904 8591 CABLE/FILTER RELAY EAH-0014 47412000 1 C
90 1904 8592 CABLE/FILTER RELAY EAH-0015 47412010 1 C
CONTRAST PCB ASSY
Item Code No. Parts Name Specification Q R
59 1904 8593 PCB EAL-0331 00400780 1 C
1904 8594 RESISTOR/VARIABLE EVLHFKA05 03100210 1 C
98 1904 8595 HARNESS ASSY EAA-2490 47410935 1 C
CASE UNIT
Item Code No. Parts Name Specification Q R
2 1904 8596 CASE/BOTTOM NO.345 24406020 1 X
10 1904 8597 FOOT/RUBBER Comes with the above parts Set 4 -
12 1904 8598 COVER/FDD EBM-0926 NO.345 24250381 1 C
11 1904 8599 COVER/POWER SWITCH EBM-0937 NO.345 24250391 1 C
9 1904 8600 COVER/BACK EBM-0927 NO.345 24250401 1 C
1 1904 8601 CASE/UPPER EDM-0915 NO.345 24106030 1 X
4 1904 8602 BASE/SHAFT EBM-0930 NO.345 24250411 1 X
5 1904 8603 COVER/BASE/SHAFT EAM-0931 NO.345 24250421 1 X
6 1904 8604 COVER/BASE/SHAFT EAM-0932 NO.345 24250431 3 X
38 1904 8605 CAM LOCK A EBM-0303 47300502 1 C
3 1904 8606 COVER/PRINTER EDM-1047 NO.345 24206030 1 C
13 1904 8607 BLIND PIECE/SCREW EAM-0954 NO.345 46200140 4 X
