— 124 —
DL-2765(DM47-4/8)
Item Code No. Parts Name Specification Q R
20 1904 8747 METAL/DRAWER SOLENOID EBM-0496 CD050004 1 C
21 SET/LATCH EBM-0453(comes with above parts) set 1 -
23 1904 8760 SPRING EAM-0118A CD060002 1 X
22 1904 8748 SOLENOID ASSY EAA-1877A CD110012 1 A
33 SCREW P.3x6 SW CD100009 2 X
25 1904 8749 SPRING/STOPPER EBM-0366 CD060004 1 X
24 1904 8750 RUBBER/STOPPER EAA-1135 CD020004 1 X
31 SCREW S-TITE TP4x16 CD100002 1 X
26 1904 8764 SWITCH/MICRO VX-014-1A3 CD120001 1 C
34 SCREW P3x15 SW CD100012 2 X
10 HOLDER/SWITCH TCE-01 CD420001 1 X
8 1904 8752 ROLLER ER-19 CD030002 4 A
9 NUT M6 CD040003 4 X
5 AXLE EAM-0093 CD380001 1 X
6 E RING EAA-1018 CD390001 1 X
7 URETHANE EAA-1019 CD230002 2 X
3 1904 8753 CAM LOCK B EBM-0306 CD370001 1 A
4 CAM LOCK KEY set 1 -
1 BASE DRAWER EDM-0913 CD580003 1 X
2 COVER/FRONT EDM-0914 No. 345 CD580004 1 X
18 OPTION DRAWER EDM-0929 No. 345 CD580005 1 X
27 SCREW S-TITE 3x6 CD100011 2 X
SHEET/INSULATION 90x30x0.2t CD230003 1 X
19 HOUSING/DRAWER EDM-0655 No. 345 CD010026 1 X
CHANGE CORE EBM-0953 1 X
35 FOOT/RUBBER ø15x11 (EAA-0998) CD020003 4 X
32 SCREW T.P(P TITE)M4x9.4(EAM-0536) CD100015 3 X
11 1904 8754 TRAY/BILL COIN EDM-0298 BLACK CD400001 1 A
12 1904 8755 PARTITION PLATE M EDM-0296 BLACK CD320005 3 A
13 1904 8756 STOPPER/BILL EBM-0085 BLACK CD330001 4 A
15 1904 8757 PIECE/ARM FITTING EAM-0092 CD340001 4 X
14 1904 8758 SPRING/ARM EAM-0601 CD060006 4 A
16 BASE PLATE M EBM-0302 CD350003 1 X
29 SCREW S TITE 3x6 CD100011 4 X
28 SCREW PTT-P.3x8 CD100008 3 X
17 PLATE/UPPER EBM-1754 No. 345 CD200060 1 X
30 SCREW S-TITE 3x8(BIND) CD100005 6 X
CLAMP/CORD CD260001 1 X
