— 5 —
1-3-2. Customer Displays
The system offers two choices of customer display.
Alphanumeric VFD The character height : 10.5mm (SA-5062DH) or 5.5mm (SA-5061D).
2 X 20 The display has a RS232C serial interface and is connected to the
9-pin D-sub connector on the rear bracket at the rear of the housing.
Numeric VFD Thecharacter height is 11 mm (SA-5060N).
1 x 11 The display has two connectors to be connected to the connectors on the
keyboard controller board inside of the unit, underneath the keyboard.
Open one of ISA expansion slot on the rear bracket and thread the cables
into the unit.
1-3-3. Operator Displays
SA-5002C VGA color LCD flat panel display
SA-5001M VGA monochrome LCD flat panel display
1-3-4. Keyboard
The keyboard contains 90 keys which can be re-labelled to support double wide, double high and
quad keys.
The scancodes are programmable. An alternative flat membrane water resistance keyboard with
120 keys is available.
1-3-5. Manager’s Electronic Keylock
The system contains a 8-position manager’s keylock.
1-3-6. Magnetic Stripe Reader
The MSR input is similar to a keyboard input.
2 tracks (track 1 and 2) is standard, 3 tracks (track 1 , 2 and 3) is optional.
1-3-7. Printers
The system housing is designed to accommodate different printer mechanisms with different covers
as indicated in the table below.
Model Type of Printer Printer Mechanism
SA-5000 Single Station Dot Matrix Citizen-614 with validation
SA-5100 Single Station Thermal Citizen-380
