Key Operation to Assign Function Keys to the Keyboard
NOTE: The three (3) online processing tender keys above are the
CREDIT, CHECK and CHARGE keys
Function Key Status Settings
The tender keys must be defined whether they are credit or debit transaction
keys.
Description Status Bit Program Setting
Credit D13 1
Discover D13 2
Debit D13 3
Gift Card D13 8
Example - To program the standard credit function key to be a credit card
electronic payment key:
PGM Mode
Enter 3 and depress Subtotal
Enter 1000000000000 and depress the CREDIT function key
Depress Subtotal to end the process
Note: After performing the above process, in REG mode if a transaction is
entered and the CREDIT key is depressed and the cash drawer opens without a
SWIPE CARD message on the operator display then it means the key was not
programmed properly. Try the programming process again.
