4) The second connector on the SP-30’s attached cable is a RJ-45 connector
used to connect the SP-30 to the Internet connection. Power to the SP-30 is
supplied by the Casio cash register, there is no external power supply for the
PAX device.
5) Upon power-up messages will appear on the Casio cash register display
saying “CREDIT INITIALIZATION… PRESS ENTER” and the PAX SP-30 will re-
boot its’ application (anytime the ECR is powered up, the PAX is also powered
up and re-boots). Before hitting the ENTER key on the cash register keyboard
make sure the READY prompt is appearing on the SP-30 display (you may have
to hit the green ENTER key on the PAX keyboard to finalize the re-boot process
and get the READY prompt). Hitting the ENTER key on the keyboard will result
in the cash register initializing the COM ports in order to recognize the PAX
device.
One of two (2) messages will appear on the operator display, “OK” if it was able
to recognize and initialize the PAX SP-30 or “FAILED” if it cannot recognize it. If
FAILED appears check the connections and the COM port programming which
will be discussed on the following pages.
The following pages will contain the Electronic Payment Processing setup
parameters for the Casio ECR’s. The ECR’s COM port must be configured in
order for the ECR to communicate with the PAX device and process
Credit/Debit/Gift card transactions.
TE-1500 & TK-1550
The following pages will contain the Electronic Payment Processing setup
parameters for the Casio ECR’s to communicate and operate with the PAX
device.
