The sequence to program these values are:
1. Turn the mode lock key on the cash register to the PGM position
2. Enter “3” from the numeric keyboard and hit the Subtotal key
3. Enter 2022 and depress the Subtotal key (this setting or address has a 8-
digit entry D8 ~ D1
a. D8 ~ D7 = Do not Issue Merchant Credit Receipt when below this
amount (2-digt entry, example: entering 25 would mean any
transaction $25.00 or less will not issue a merchant receipt but will
issue customer receipt)
b. D6 = (in this bit the sum of each feature is entered in D6)
iv. 1 = Zip Code input required for Manual Credit Card operation
v. 2 = CVV input required for Manual Credit Card operation
vi. 4 = Address input required for Manual Credit Card operation
c. D5 = Debit Cash Back 1
st
Amount – (0=none, 1=$10, 2=$20….
9=$90)
d. D4 = Debit Cash Back 2
nd
Amount – (0=none, 1=$10, 2=$20….
9=$90)
e. D3 = Debit Cash Back 3
rd
Amount – (0=none, 1=$10, 2=$20….
9=$90)
f. D2 = Debit Cash Back 4
th
Amount – (0=none, 1=$10, 2=$20….
9=$100)
g: D1 = (in this bit the sum of each feature is entered in D1)
v. 1 = Tip format (a tip, total with tip and signature line printing
vi. 2 = Demo Mode (testing and demonstrations purposes this
bit will set the PAX SP-30 in Demo Mode)
vii. 0 = Retail Mode
viii. 4 = Restaurant Mode – (any hospitality operation performing
a charge tip operation requires this feature activated)
Summary: Below is a summary program setting for 2022 address
2022 – D8 D7 D6 D5 ~ D2 D1
Cash Back
Values for Debit
transactions
Zip or CVV
entry on
manual card
1=Zip Code
2=CVV
4=Address
1=Tip/Total Line
2=Demo
4=Restaurant Mode
$ amount
not to print
store credit
card receipt
