Once a machine has the desired IPL there is the ability to load the IPL from a
machine to a RAC-12B card using following the steps:
1) Turn Mode key to “OFF” position and hold down the Journal Feed key and
turn the Mode Lock key to the “PGM” position
2) Wait a few seconds and release the Journal Feed key
3) The machine will beep and the following screen will appear
4) Insert the RAC Card into the RAC slot on the left side of the machine as
shown below:
5) When inserting the RAC Card the arrow on the card should be facing up
as shown below:
6) Enter 99990000 and depress SUBTOTAL
7) Next enter 714 and depress SUBTOTAL
8) At this time the machine will proceed to load the IPL to the RAC Card and
the following will appear on the display:
Into RAC Card slot in machine
Load IPL from Machine to RAC-12 Card
To Next Page
Loading...
